6105-00-331-2391
Control Motor
6105003312391 003312391 R110-3A IMC-007 8015913 5153-20 C45-5153-20 GA51234
A motor which is designed to be operated from two independent voltage sources, in such a way that variations in one voltage source will determine the direction and speed of the motor. In the alternating current type the voltages are usually applied to a split-phase stator, whereas in the direct current type, one voltage is applied to the stator and the other to the armature. Low inertia and rapid reversibility are inherent characteristics of this type of motor. See also SERVOMOTOR, AUTOMATIC PILOT. View more Control Motor
May 2023
30
Marketplace 6105-00-331-2391
Request a Quotation from participating marketplace vendors
Related Documents 6105-00-331-2391 4+ Documents (More...)
IMC-007 MOTOR,CONTROL 3 EA NS Request Quotation Updated Every Day 6105-00-331-2391 RQST NE Updated Every
to be operated from two IMC-007 MOTOR,CONTROL 3 EA NS Request Quotation Updated Every Day 6105-00-331
Documents 1620-14-280-0658 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-61/fsc-6105/us 6105-00-331-2391
Control Motor 6105003312391 003312391,R110-3A 6105-00-331-2391Control Motor6105003312391 003312391
Request Quotation R-110-3A MOTOR,CONTROL 1 EA NS Request Quotation Subscribe to View Vendor Details... 5153-20
48586105006354858006354858 MOTOR,CONTROL Restrictions https//www.nsnlookup.com /fsg-61/fsc-6105/us 6105-00-331-2391
Restrictions 6105-00-331-2391
6105-00-331-2391 is a Control Motor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6105-00-331-2391
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6105-00-331-2391
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- N9GD
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 6105-00-331-2391
- Part Number
- Manufacturer
- Status
- R110-3A
- Manufacturer
- 05088 - Kearfott Corp (Active)
- Primary Buy
- Primary Buy
- IMC-007
- 40968 - Island Components Group Inc (Active)
- Primary Buy
- Primary Buy
- 8015913
- 18876 - Us Army Aviation And Missile Command (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- R110-3A
- 88818 - Kearfott Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8015913
- 88818 - Kearfott Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5153-20
- 58880 - Meggitt (New Hampshire), Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- C45-5153-20
- 99932 - Moog Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GA51234
- 64959 - American Telephone And Telegraph Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- GA51234
- 70408 - At And T Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6105-00-331-2391
- Characteristic
- Specifications
- FIIG
- Specifications
- A271A0
- Connection Type And Voltage Rating In Volts [CWGQ]
- 115.0 Konica, Qh Four-Spline Input
- Cooling Method [BFMF]
- Nonventilated
- Control Field Voltage Type And Rating In Volts [BKPS]
- 115.0 Ac
- Control Field Winding Type [BFML]
- Two Windings, Series Connected Or Two Windings, Parallel Connected
- Current Type [ACDC]
- Ac Input
- Features Provided [CBBL]
- Horizontal Mounting Position And Vertical Mounting Position
- Frequency In Hertz [FREQ]
- 400.0 Input
- Maximum Operating Altitude Rating [AKAE]
- 30000.0 Feet
- Mounting Facility Circle Diameter [CWFQ]
- 1.100 Inches
- Mounting Facility Type And Quantity [AXHR]
- 4 Threaded Hole
- Mounting Method [AXGY]
- Face
- Overall Length [AAJU]
- 2.392 Inches
- Inclosure Feature [ANPZ]
- Totally Inclosed
- Inclosure Specification [BKPQ]
- Commercial
- Length Of Shaft From Housing [CWCS]
- 0.540 Inches Single End
- Rotor Speed Rating In Rpm [CWFX]
- 2800.0 Low No Load And 5300.0 High No Load
- Shaft Diameter [ABWV]
- 0.120 Inches Nominal Single End
- Shaft End Characteristic [CWHZ]
- A1 Single Style Single End
- Overall Height [AAJT]
- 1.437 Inches
- Overall Width [AAJV]
- 1.312 Inches
- Phase [FAAZ]
- Two Input
- Temp Rating [CWDY]
- -54.0 Operating Deg Celsius And 125.0 Operating Deg Celsius
- Terminal Type And Quantity [TTQY]
- 6 Screw
- Torque Rating And Type [BKPH]
- 1.5 Inch-Ounces Stalled
DLA Procurement Analysis 6105-00-331-2391
Management Data 6105-00-331-2391
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 6105-00-331-2391
Freight Information 6105-00-331-2391
6105-00-331-2391 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 6105-00-331-2391 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6105-00-331-2391 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 6105-00-331-2391 is not classified as a special type of cargo when transported by water. 6105-00-331-2391 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
