6105-00-110-7809
Alternating Current Motor
6105001107809 001107809 5KCP39JG3318T 3M810 S3282 D1036-S 5KCP39MG3318S
A motor which is designed for operation from an alternating current source. See also MOTOR, CONTROL. View more Alternating Current Motor
Managed by United States
NSN Created on 20 Dec 1972
Data Last Changed
August 2023
August 2023
NATO Update Count
10
10
NATO Data Quality
Marketplace 6105-00-110-7809
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Updated 22 Days Ago
S3282 MOTOR 3 EA NS
FedMall
Updated Every 15 Minutes
Updated Every 15 Minutes 6105-00-110-7809 BUY NE FedMall
Updated Every Day 3M810 RQST NE
Updated Every Day 6105-00-110-7809 RQST NE
Updated Every Day 6105-00-110-7809 RQST
Updated Every Day 6105-00-110-7809 RQST NE
Related Documents 6105-00-110-7809 5+ Documents (More...)
5KCP39JG3318T 3M810 S3282 D1036-S 5KCP39MG3318S A motor which is designed for operation from an alternating
S3282 MOTOR 3 EA NS Request Quotation FedMall Updated Every 15 Minutes 6105-00-110-7809 BUY NE FedMall
Updated Every Day 3M810 RQST NE Updated Every Day 6105-00-110-7809 RQST NE Updated Every Day 6105-00
S3282 MOTOR 3 EA NS Request Quotation FedMall Updated Every 15 Minutes 6105-00-110-7809 BUY NE FedMall
Updated Every Day 3M810 RQST NE Updated Every Day 6105-00-110-7809 RQST NE Updated Every Day 6105-00
how to enable JavaScript in your web browser . 4820-99-526-9744Angle Valve4820995269744 995269744 S3282
Current Motor6105001107809 001107809 5KCP39JG3318T 3M810 S3282 https//www.nsnlookup.com /fsg-61/fsc-
6105/us 6105-00-110-7809 Alternating Current Motor 6105001107809 Account Upgrade 6105-00-110-7809Alternating
Current Motor6105001107809 001107809 5KCP39JG3318T 3M810 S3282 https//www.nsnlookup.com /fsg-61/fsc-
6105/us 6105-00-110-7809 Alternating Current Motor 6105001107809 Account Upgrade 6105-00-110-7809Alternating
https//www.nsnlookup.com /fsg-48/fsc-4820/uk 4820-99-526-9744 Angle Valve 4820995269744 995269744,S3282
Kingdom NSN Created on 2 Sep 1989 Data Last Changed https//www.nsnlookup.com /fsg-61/fsc-6105/us 6105-00-110-7809
Alternating Current Motor 6105001107809 Upgrade 6105-00-110-7809Alternating Current Motor6105001107809
Kingdom NSN Created on 2 Sep 1989 Data Last Changed https//www.nsnlookup.com /fsg-61/fsc-6105/us 6105-00-110-7809
Alternating Current Motor 6105001107809 Upgrade 6105-00-110-7809Alternating Current Motor6105001107809
9422Preformed Packing5330997489422 997489422 38091 10904 S3282ITEM8 VW611575-8 3513 724 01027 A/38091 S3282
Packing5330997489422 9974894223809110904S3282ITEM8 VW611575-83513 724 01027A/38091S3282/8H577-374890 2 DAC 2 S3282
RNVC 2 DAC 2 A/38091 K3586 - Lightfoot Defence Limited (Active) Secondary Buy RNCC 5 RNVC 2 DAC 2 S3282
Packing5330997489422 9974894223809110904S3282ITEM8 VW611575-83513 724 01027A/38091S3282/8H577-374890 2 DAC 2 S3282
RNVC 2 DAC 2 A/38091 K3586 - Lightfoot Defence Limited (Active) Secondary Buy RNCC 5 RNVC 2 DAC 2 S3282
Restrictions 6105-00-110-7809
6105-00-110-7809 is a Alternating Current Motor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6105-00-110-7809
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6105-00-110-7809
- US Army (A920)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- A183
- US Air Force (FXGG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- FXCX
- NASA (G26X)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- G26G
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
Approved Sources 6105-00-110-7809
- Part Number
- Manufacturer
- Status
- 5KCP39JG3318T
- Manufacturer
- 9A544 - General Electric Supply Co Div Of (Active)
- Primary Buy
- Primary Buy
- 3M810
- 25795 - W.W. Grainger, Inc. (Active)
- Primary Buy
- Primary Buy
- 3M810
- 7D665 - Grainger Div Of W W Grainger Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- S3282
- 28891 - United Technologies-Essex/Iwi Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- D1036-S
- 5Y113 - Arlet Mfg Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5KCP39MG3318S
- 28891 - United Technologies-Essex/Iwi Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6105-00-110-7809
- Characteristic
- Specifications
- FIIG
- Specifications
- A271A0
- Duty Cycle [AKPS]
- Continuous
- Connection Type And Voltage Rating In Volts [CWGQ]
- 208.0 Line To Neutral Low Input Or 230.0 Line To Neutral High Input
- Cooling Method [BFMF]
- Natural Convection Ventilated
- Current Rating In Amps [CWGL]
- 2.400 Single Input
- Current Rating Method [BKPB]
- Load
- Features Provided [CBBL]
- Thermal Protective Device And Horizontal Mounting Position And Vertical Mounting Position
- Flat Depth [AGRB]
- 0.050 Inches Nominal Single End
- Flatted Portion Length [ABXQ]
- 4.000 Inches Nominal Single End
- Frequency In Hertz [FREQ]
- 60.0 Input
- Mounting Facility Type And Quantity [AXHR]
- 2 Clamp Collar
- Mounting Method [AXGY]
- Resilient Ring
- Overall Length [AAJU]
- 9.641 Inches
- Inclosure Feature [ANPZ]
- Open Protected
- Inclosure Specification [BKPQ]
- Commercial
- Length Of Shaft From Housing [CWCS]
- 4.000 Inches Single End
- Power Rating [CNXS]
- 0.333 Horsepower Output
- Rotor Speed Rating In Rpm [CWFX]
- 1075.0 Single Full Load
- Shaft Diameter [ABWV]
- 0.500 Inches Nominal Single End
- Shaft End Characteristic [CWHZ]
- A5 Single Style Single End
- Shaft Rotation Direction [AKCT]
- Clockwise Single End
- Overall Height [AAJT]
- 6.830 Inches
- Overall Width [AAJV]
- 6.330 Inches
- Phase [FAAZ]
- Single Input
- Winding Type [AXCP]
- Induction-Permanent Split Capacitor Split Phase
- Terminal Type And Quantity [TTQY]
- 3 Wire Lead
DLA Procurement Analysis 6105-00-110-7809
Management Data 6105-00-110-7809
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 6105-00-110-7809
Freight Information 6105-00-110-7809
6105-00-110-7809 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 6105-00-110-7809 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6105-00-110-7809 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 6105-00-110-7809 is not classified as a special type of cargo when transported by water. 6105-00-110-7809 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
