6105-00-104-4348
Alternating Current Motor
6105001044348 001044348 6K734 6K032
A motor which is designed for operation from an alternating current source. See also MOTOR, CONTROL. View more Alternating Current Motor
May 2023
18
Marketplace 6105-00-104-4348
Request a Quotation from participating marketplace vendors
Related Documents 6105-00-104-4348 5+ Documents (More...)
BUY NE FedMall Updated Every Day 6K734 RQST NE Updated Every Day 6K032 RQST NE Updated Every Day
6105-00-104-4348 RQST NE Updated Every Day 6105-00-104-4348 RQST Updated Every Day 6105-00-104-4348
Alternating Current Motor 6105001044348 day Upgrade your Account Upgrade 6105-00-104-4348Alternating
Current Motor6105001044348 001044348 6K734 vendors Request FedMall Updated Every 15 Minutes 6105-00-
6105-00-888-2421 6105-00-332-5270 082-0333 6105-00-343-1646 6105-00-060-5273 6105-01-578-8842 6105-00-104-4348
052-5044 6105990525044 990525044 082-0333 6105-00-343-1646 6105-00-060-5273 6105-01-578-8842 6105-00-104-4348
-007-7010 Alternating Current Motor 6105210077010 082-0333 6105-00-343-1646 6105-01-578-8842 6105-00-104-4348
-897-2309 Alternating Current Motor 6105218972309 082-0333 6105-00-343-1646 6105-01-578-8842 6105-00-104-4348
fsc-6105/uk 6105-99-096-1459 Alternating Current Motor 6105990961459 343-1646 6105-01-578-8842 6105-00-104-4348
Items to 6105-01-108-9225 6105-01-288-6882 6105-01-607-9567 6105-01-198-9433 6105-00-082-0333 6105-00-104-4348
Restrictions 6105-00-104-4348
6105-00-104-4348 is a Alternating Current Motor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6105-00-104-4348
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6105-00-104-4348
- US Navy (N9BG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
Approved Sources 6105-00-104-4348
- Part Number
- Manufacturer
- Status
- 6K734
- Manufacturer
- 25795 - W.W. Grainger, Inc. (Active)
- Primary Buy
- Primary Buy
- 6K032
- 25795 - W.W. Grainger, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6105-00-104-4348
- Characteristic
- Specifications
- FIIG
- Specifications
- A271A0
- Duty Cycle [AKPS]
- Continuous
- Connection Type And Voltage Rating In Volts [CWGQ]
- 115.0 Line To Neutral Single Input
- Cooling Method [BFMF]
- Nonventilated
- Current Rating In Amps [CWGL]
- 4.500 Single Input
- Current Rating Method [BKPB]
- Load
- Features Provided [CBBL]
- Automatic Reset And Horizontal Mounting Position
- Frame Size Designation [CNMM]
- 56
- Frequency In Hertz [FREQ]
- 60.0 Input
- Mounting Facility Type And Quantity [AXHR]
- 4 Slot
- Mounting Method [AXGY]
- Fixed Base
- Nominal Center To Center Distance Between Mounting Facilities Parallel To Length [CWDT]
- 3.000 Inches
- Nominal Center To Center Distance Between Mounting Facilities Parallel To Width [CWFY]
- 4.875 Inches
- Overall Length [AAJU]
- 13.500 Inches
- Inclosure Feature [ANPZ]
- Totally Inclosed
- Inclosure Specification [BKPQ]
- Nema
- Keyway Length [AFYS]
- 1.375 Inches Nominal Single End
- Keyway Width [ABRR]
- 0.188 Inches Nominal Single End
- Keyway Depth [ABRV]
- 0.094 Inches Nominal Single End
- Length Of Shaft From Housing [CWCS]
- 1.875 Inches Single End
- Power Rating [CNXS]
- 0.250 Horsepower Output
- Rotor Speed Rating In Rpm [CWFX]
- 1725.0 Single Full Load
- Shaft Center To Mounting Surface Distance [CWDM]
- 3.484 Inches Single End
- Shaft Diameter [ABWV]
- 0.625 Inches Nominal Single End
- Shaft End Characteristic [CWHZ]
- A9 Single Style Single End
- Shaft Rotation Direction [AKCT]
- Clockwise Single End Or Counterclockwise Single End
- Overall Height [AAJT]
- 6.938 Inches
- Overall Width [AAJV]
- 7.438 Inches
- Phase [FAAZ]
- Single Input
- Winding Type [AXCP]
- Induction-Split Phase
- Temp Rating [CWDY]
- 40.0 Ambient Deg Celsius And 55.0 Operating Deg Celsius
- Terminal Type And Quantity [TTQY]
- 5 Wire Lead
DLA Procurement Analysis 6105-00-104-4348
Management Data 6105-00-104-4348
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 6105-00-104-4348
Freight Information 6105-00-104-4348
6105-00-104-4348 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 6105-00-104-4348 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6105-00-104-4348 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 6105-00-104-4348 is not classified as a special type of cargo when transported by water. 6105-00-104-4348 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
