5999-01-352-9807
Light-Switch Assembly
5999013529807 013529807 6981ED173-508
An electrical device consisting of a Switch (1) and two or more lights, or two or more switches and two or more lights, mounted on a common mounting. The lights are not intended for illumination but are present for the purpose of indication. Each item may be separable and capable of functioning individually, or the items may be fabricated into a common inseparable body, incapable of functioning individually. It may include wall plate or box cover and it may be complete with box. Excludes push, pull, push-pull, and toggle switches with a lamp mounted integrally in the actuator. View more Light-Switch Assembly
November 2023
2
Marketplace 5999-01-352-9807
Request a Quotation from participating marketplace vendors
Related Documents 5999-01-352-9807 1+ Documents (More...)
LIGHT-SWITCH ASSEMBLY 1 EA NS Request Quotation FedMall Updated Every 15 Minutes 5999-01-352-9807
BUY NE FedMall Updated Every Day 5999-01-352-9807 RQST NE Updated Every Day 5999-01-352-9807 RQST Updated
Restrictions 5999-01-352-9807
5999-01-352-9807 is a Light-Switch Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5999-01-352-9807
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5999-01-352-9807
- US Navy (N9BN)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
Approved Sources 5999-01-352-9807
- Part Number
- Manufacturer
- Status
- 6981ED173-508
- Manufacturer
- 27192 - Drs Naval Power Systems Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 5999-01-352-9807
- Characteristic
- Specifications
- FIIG
- Specifications
- A507C0
- Component Type And Quantity [CXCK]
- 1 Light And 2 Switch
- Contact Arrangement [APFR]
- Single Pole, Double Throw, Both Positions Maintained
- Material [MATT]
- Steel
- Mounting Method [AXGY]
- Unthreaded Hole
- Lens Color [AEXD]
- Green
- Shape [SHPE]
- Rectangular
- Overall Height [ABKW]
- 4.100 Inches Maximum
- Overall Length [ABHP]
- 8.000 Inches Nominal
- Overall Width [ABMK]
- 3.750 Inches Nominal
- Switch Type [AEEA]
- Push
Weapon Systems (WSDC) 5999-01-352-9807
DLA Procurement Analysis 5999-01-352-9807
- Last Stock Position:
- 3 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5999-01-352-9807
Navy
- Cognizance:
- 3B
Similar Supply Items to 5999-01-352-9807
Freight Information 5999-01-352-9807
5999-01-352-9807 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 5999-01-352-9807 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 5999-01-352-9807 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5999-01-352-9807 is not classified as a special type of cargo when transported by water. 5999-01-352-9807 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5999-01-352-9807
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 10.0" H x 5.0" W x 3.0" L
- --
- --
- --
- Any Suitable Process
- 10.0" H x 5.0" W x 3.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 5999-01-352-9807 4 Records
Contracting Technical Data File (CTDF) 5999-01-352-9807 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
