5995-00-679-9202
Radio Frequency Cable Assembly
5995006799202 006799202 8756712 2590006799202 5995PL1483156
A definite length of CABLE, RADIO FREQUENCY having one or both ends processed and/or terminated in fittings which provide for connection to other items. Includes multiple cable assemblies in a common jacket or shield. Excludes items having branches or forks and LEAD, TEST. See also CABLE ASSEMBLY, RADIO FREQUENCY, BRANCHED. View more Radio Frequency Cable Assembly
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
42
42
NATO Data Quality
Marketplace 5995-00-679-9202
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5995-00-679-9202 5+ Documents (More...)
8756712 2590006799202 5995PL1483156 A definite length of CABLE, RADIO FREQUENCY having one or both ends
Photo 1/2 NSN 5995-00-679-9202 (Identification) 2/2 - - 1.
Updated Every Day 5995-00-679-9202 RQST Updated Every Day 5995-00-679-9202 RQST NE Related Documents
Photo 1/2 NSN 5995-00-679-9202 (Identification) 2/2 - - 1.
Updated Every Day 5995-00-679-9202 RQST Updated Every Day 5995-00-679-9202 RQST NE Related Documents
356-2410 5995-01-376-1544 5995-01-249-2281 5995-01 512-2764 5995-00-110-6718 5995-00-434-0646 5995-00-679-9202
-1544 5995-01-249-2281 5995/us 5995-01-004-9139 https//www.nsnlookup.com /fsg-59/fsc-5995/us 5995-00-679-9202
Radio Frequency Cable Assembly 5995006799202 Day 5995-00-679-9202 RQST NE Related Documents https
-1544 5995-01-249-2281 5995/us 5995-01-004-9139 https//www.nsnlookup.com /fsg-59/fsc-5995/us 5995-00-679-9202
Radio Frequency Cable Assembly 5995006799202 Day 5995-00-679-9202 RQST NE Related Documents https
6788 Radio Frequency Cable Assembly 5995226136788 https//www.nsnlookup.com /fsg-59/fsc-5995/us 5995-00-679-9202
Radio Frequency Cable Assembly 5995006799202 /fsg-59/fsc-5995/us 5995-01-004-9139 Radio Frequency
-249-1371 5995-01-293-1432 5995-01-004-9139 Assembly 6145993402402 110-6718 5995-00-434-0646 5995-00-679-9202
Radio Frequency Cable Assembly 5995006799202 /fsg-59/fsc-5995/us 5995-01-004-9139 Radio Frequency
-249-1371 5995-01-293-1432 5995-01-004-9139 Assembly 6145993402402 110-6718 5995-00-434-0646 5995-00-679-9202
Radio Frequency Cable Assembly 6625222830636 679-9202 5995-01-249-1371 5995-01-293-1432 5995/dk 5995-00-679-9202
498-8125 5995-01-278-1271 5995-00-539-0169 5995-01-512-2764 5995-00-110-6718 5995-00-434-0646 5995-00-679-9202
498-8125 5995-01-278-1271 5995-00-539-0169 5995-01-512-2764 5995-00-110-6718 5995-00-434-0646 5995-00-679-9202
fsc-5360/us 5360-00-006-3771 Special Spring 5360000063771 000063771,249 6718 5995-00-434-0646 5995-00-679-9202
498-8125 5995-01-278-1271 5995-00-539-0169 5995-01-512-2764 5995-00-110-6718 5995-00-434-0646 5995-00-679-9202
498-8125 5995-01-278-1271 5995-00-539-0169 5995-01-512-2764 5995-00-110-6718 5995-00-434-0646 5995-00-679-9202
Restrictions 5995-00-679-9202
5995-00-679-9202 is a Radio Frequency Cable Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5995-00-679-9202
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5995-00-679-9202
- US Army (A918)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- A178
- Supplementary Receivers:
- AZ
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Lithuania (WI01)
- Effective Date:
- 1 Sep 2001
- Brazil (YA01)
- Effective Date:
- 1 Jan 2002
- Spain (YB01)
- Effective Date:
- 1 Aug 1995
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Oct 1999
Approved Sources 5995-00-679-9202
- Part Number
- Manufacturer
- Status
- 8756712
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 2590006799202
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5995PL1483156
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 5995-00-679-9202
- Characteristic
- Specifications
- FIIG
- Specifications
- A077A0
- Electrical Resistance [AAPP]
- 50.00 Ohms Impedance
- Conductor Form [CXCW]
- Stranded Single Conductor
- Conductor Arrangement And Quantity [CXDQ]
- 1 Coaxial
- Cross Section Outside Diameter [ADVL]
- 0.405 Inches Nominal
- Cross-Sectional Shape Style [AAGR]
- Round
- Fsc Application Data [ZZZV]
- Cable Assemblies,Electrical,Specialized Vehicular
- Conductor Quantity [AMQN]
- 1
- Material [MATT]
- Copper 2Nd Position Shield Braid, Metallic Single Conductor
- Material [MATT]
- Copper Core Conductor Single Conductor
- Material [MATT]
- Plastic Polyvinyl Chloride 3Rd Position Jacket Single Conductor
- Material [MATT]
- Plastic Polyethylene Terephthalate 1St Position Primary Insulation Single Conductor
- Round Conductor Size [CXDC]
- 13 Awg Single Conductor
- Overall Length [AAJU]
- 52.000 Inches
- Strand Quantity Per Conductor [BLNZ]
- 7 Single Conductor
- Strand Awg Size Per Conductor [CXDG]
- 21 Single Conductor
- Terminal Commercial And Government Entity Code [CXGN]
- 19204 Both Ends Single Conductor
- Termination Type [AKRZ]
- Connector Plug Both Ends Single Conductor
Weapon Systems (WSDC) 5995-00-679-9202
DLA Procurement Analysis 5995-00-679-9202
- Last Stock Position:
- 16 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5995-00-679-9202
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Nov 2007
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- V
- Discontinued W/O Replacement
- V
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- A2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 5995-00-679-9202
Freight Information 5995-00-679-9202
5995-00-679-9202 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061130. A Sub NMFC of X. It has a NMFC Description of CABLE ASSEMBLY. 5995-00-679-9202 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34350 which rates the freight between FCL and LCL. 5995-00-679-9202 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 743 for ocean manifesting and military sealift. 5995-00-679-9202 is not classified as a special type of cargo when transported by water. 5995-00-679-9202 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5995-00-679-9202
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 52.0" H x -- W x -- L
- --
- --
- Physical Protection
- Any Suitable Process
- 52.0" H x -- W x -- L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- ASTM - D5118, Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 5995-00-679-9202 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
