5995-00-674-8737
Electrical Lead
5995006748737 006748737 10864169 2590006748737
A definite length of one-conductor electrical wire, wire braid, or other conductive material, except cable or cord, one or both ends of which are processed or terminated. The lead may be of any size or shape, insulated or uninsulated. See also LEAD, TEST and BUS CONDUCTOR. Excludes LEAD, STORAGE BATTERY; LEAD, IGNITION, ENGINE, and items having attached switches, lampholders, suppressors, resistors, and the like. View more Electrical Lead
November 2023
25
Marketplace 5995-00-674-8737
Request a Quotation from participating marketplace vendors
Related Documents 5995-00-674-8737 5+ Documents (More...)
Photo 1/2 NSN 5995-00-674-8737 (Identification) 2/2 - - 1.
United States (US) 4. 5995-00-674-8737 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 5995-00-674-8737
5995-00-674-8737 is a Electrical Lead that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5995-00-674-8737
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5995-00-674-8737
- US Army (A918)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- A178
- Supplementary Receivers:
- AZ
- US Marine Corps (MC41)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- MC04
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Sep 2011
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 2014
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5995-00-674-8737
- Part Number
- Manufacturer
- Status
- 10864169
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 10864169
- 1UHB2 - Concord Components Inc (Active)
- Secondary Buy
- Secondary Buy
- 2590006748737
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 5995-00-674-8737
- Characteristic
- Specifications
- FIIG
- Specifications
- A077A0
- Color [HUES]
- Black Core Conductor Single Conductor
- Conductor Form [CXCW]
- Stranded Single Conductor
- Cross Section Outside Diameter [ADVL]
- 0.672 Inches Nominal
- Cross-Sectional Shape Style [AAGR]
- Round
- Material Document And Classification [MDCL]
- Qq-W-343,Soft Fed Std All Material Responses Core Conductor Single Conductor
- Material [MATT]
- Cotton 2Nd Position Braid, Non-Metallic Single Conductor
- Material [MATT]
- Copper Core Conductor Single Conductor
- Material [MATT]
- Rubber Synthetic 1St Position Primary Insulation Single Conductor
- Material [MATT]
- Rubber Chloroprene Class Cr 3Rd Position Sheath Single Conductor
- Lead Overall Length [AXBQ]
- 216.000 Inches Nominal
- Round Conductor Size [CXDC]
- 0 Awg Single Conductor
- Special Features [FEAT]
- G1 Marker Band,2 Grommets,2 Nuts
- Strand Awg Size Per Conductor [CXDG]
- 30 Single Conductor
- Strand Quantity Per Conductor [BLNZ]
- 1033 Single Conductor
- Terminal Commercial And Government Entity Code [CXGN]
- 19207 Both Ends Single Conductor
- Termination Type [AKRZ]
- Connector Plug 2Nd End Single Conductor
- Termination Type [AKRZ]
- Connector Receptacle 1St End Single Conductor
Weapon Systems (WSDC) 5995-00-674-8737
DLA Procurement Analysis 5995-00-674-8737
- Last Stock Position:
- 4 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5995-00-674-8737
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 5995-00-674-8737
Freight Information 5995-00-674-8737
5995-00-674-8737 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062360. A Sub NMFC of X. It has a NMFC Description of LEADS/LEAD WIRES ELEC ARTICLE ETC. 5995-00-674-8737 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34890 which rates the freight between FCL and LCL. 5995-00-674-8737 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 743 for ocean manifesting and military sealift. 5995-00-674-8737 is not classified as a special type of cargo when transported by water. 5995-00-674-8737 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5995-00-674-8737
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 216.0" H x -- W x -- L
- --
- --
- Physical Protection
- Any Suitable Process
- 216.0" H x -- W x -- L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- ASTM - D5118, Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 5995-00-674-8737 4 Records
Contracting Technical Data File (CTDF) 5995-00-674-8737 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
