5995-00-187-9790
Radio Frequency Cable Assembly
5995001879790 001879790 90071-1 90071
A definite length of CABLE, RADIO FREQUENCY having one or both ends processed and/or terminated in fittings which provide for connection to other items. Includes multiple cable assemblies in a common jacket or shield. Excludes items having branches or forks and LEAD, TEST. See also CABLE ASSEMBLY, RADIO FREQUENCY, BRANCHED. View more Radio Frequency Cable Assembly
May 2023
16
Marketplace 5995-00-187-9790
Request a Quotation from participating marketplace vendors
Related Documents 5995-00-187-9790 5+ Documents (More...)
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 90071
CABLE ASSEMBLY,RADIO FREQUENCY 135 EA NS Request Quotation Subscribe to View Vendor Details... 90071
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 90071
-1 TUBE ASSEMBLY,METAL 17 EA NS Request Quotation Subscribe to View Vendor Details... 90071-1 TUBE ASSEMBLY
-7 90071-4 A hand held tool designed to install various types of terminals on electrical conductors.
https//www.nsnlookup.com /fsg-59/fsc-5995/us 5995-00-187-9790 Radio Frequency Cable Assembly 5995001879790
Upgrade your Account Upgrade 5999-01-673-8733Conductive Gasketing Material5999016738733 01673873339920-90071
Radio Frequency Cable Assembly 5995001879790 Quotation Subscribe to View Vendor Details... 90071
www.nsnlookup.com /fsg-59/fsc-5999/us 5999-01-194-3736 Electrical Contact 5999011943736011943736 66506-262828-90071
Upgrade your Account Upgrade 5999-01-194-3736Electrical Contact5999011943736 01194373666506-262828-90071
Restrictions 5995-00-187-9790
5995-00-187-9790 is a Radio Frequency Cable Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5995-00-187-9790
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5995-00-187-9790
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5995-00-187-9790
- Part Number
- Manufacturer
- Status
- 90071-1
- Manufacturer
- 88869 - Eaton Corp Electronic (Obsolete)
- Original Design
- Original Design
- 90071
- 88869 - Eaton Corp Electronic (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5995-00-187-9790
- Characteristic
- Specifications
- FIIG
- Specifications
- A077A0
- Electrical Resistance [AAPP]
- 88.00 Ohms Impedance And 98.00 Ohms Impedance
- Accessory Wire Type And Quantity [AWTB]
- 1 Ground
- Conductor Arrangement And Quantity [CXDQ]
- 1 Coaxial
- Conductor Form [CXCW]
- Solid Single Conductor
- Cross Section Outside Diameter [ADVL]
- 0.242 Inches Nominal
- Cross-Sectional Shape Style [AAGR]
- Round
- Fsc Application Data [ZZZV]
- Radar Test Set
- Conductor Quantity [AMQN]
- 1
- Material Document And Classification [MDCL]
- Qq-W-345 Fed Spec All Material Responses 1St Position Conductor All Conductors
- Material [MATT]
- Copper 2Nd Position Conductor Single Conductor
- Material [MATT]
- Steel 1St Position Conductor Single Conductor
- Round Conductor Size [CXDC]
- 22 Awg Single Conductor
- Overall Length [AAJU]
- 38.562 Inches
- Terminal Commercial And Government Entity Code [CXGN]
- 78591 2Nd End Single Conductor
- Terminal Commercial And Government Entity Code [CXGN]
- 80058 1St End Single Conductor
- Terminal Lug Aperture Size [CXFM]
- 0.169 Inches 2Nd End Single Conductor
- Terminal Manufacturer Identifying Reference Number [CXGG]
- 70082 2Nd End Single Conductor
- Terminal Manufacturer Identifying Reference Number [CXGG]
- Ug-260/U 1St End Single Conductor
- Termination Type [AKRZ]
- Connector Plug 1St End Single Conductor
- Termination Type [AKRZ]
- Lug Terminal W/Mounting Slot 2Nd End Single Conductor
Similar Supply Items to 5995-00-187-9790
Freight Information 5995-00-187-9790
5995-00-187-9790 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061320. A Sub NMFC of X. It has a NMFC Description of COAXIAL TRANSMISSION LINE/FITTINGS. 5995-00-187-9790 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 5995-00-187-9790 is rated as class 100 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34415 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5995-00-187-9790 is not classified as a special type of cargo when transported by water. 5995-00-187-9790 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
