5995-00-059-5179
Electrical Cord Assembly
5995000595179 000595179 SM-B-430301 21948
A definite length of CORD, ELECTRICAL having one or both ends processed and/or terminated in fittings which provide for connection to another item. It is generally used with telephone and communication equipment, such as headsets, category cable and switchboard patch cable. See also CABLE ASSEMBLY, (as modified and LEAD (as modified.) View more Electrical Cord Assembly
August 2023
28
Marketplace 5995-00-059-5179
Request a Quotation from participating marketplace vendors
Related Documents 5995-00-059-5179 5+ Documents (More...)
/fsg-59/fsc-5995/us
SM-B-430301 CORD ASSEMBLY,ELECTRICAL RQST NS Request Quotation Subscribe to View Vendor Details... 21948
/fsg-59/fsc-5995/us 5995-00-059-5179 Electrical Cord Assembly 5995000595179 SM-B-43030121948 A definite
Electrical Cord Assembly 5995000595179 Upgrade your Account Upgrade 5995-00-059-5179Electrical
Cord Assembly5995000595179 000595179 SM-B-430301 SM-B-430301 CORD ASSEMBLY,ELECTRICAL RQST NS Request
METER,SPECIAL SCALE 3 EA NS Request Quotation Subscribe to View Vendor Details... 21948 METER,SPECIAL
(Active) Primary Buy RNCC 3 RNVC 2 DAC 5 04-21948 https//www.nsnlookup.com /fsg-59/fsc-5962/us 5962-
METER,SPECIAL SCALE 3 EA NS Request Quotation Subscribe to View Vendor Details... 21948 METER,SPECIAL
Electrical Cord Assembly 5995000595179 METER,SPECIAL SCALE 3 EA NS Request Quotation Subscribe
/fsg-59/fsc-5995/us
Restrictions 5995-00-059-5179
5995-00-059-5179 is a Electrical Cord Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5995-00-059-5179
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5995-00-059-5179
- US Army (A918)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- A178
- Supplementary Receivers:
- BD
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 5995-00-059-5179
- Part Number
- Manufacturer
- Status
- SM-B-430301
- Manufacturer
- 80063 - Us Army Communications & Electronics (Active)
- Primary Buy
- Primary Buy
- 21948
- 18068 - Astrocom Electronics Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5995-00-059-5179
- Characteristic
- Specifications
- FIIG
- Specifications
- A077A0
- Color [HUES]
- Green 1St Position Primary Insulation Second Conductor
- Color [HUES]
- Red 1St Position Primary Insulation First Conductor
- Conductor Arrangement And Quantity [CXDQ]
- 2 Singles And 2 Twisted Pair
- Conductor Form [CXCW]
- Stranded All Conductors
- Cross Section Outside Diameter [ADVL]
- 0.160 Inches Nominal
- Cross-Sectional Shape Style [AAGR]
- Round
- Conductor Quantity [AMQN]
- 2
- Material [MATT]
- Cadmium Core Conductor All Conductors
- Material [MATT]
- Cotton 1St Position Wrap All Conductors And Rubber Polychloroprene 1St Position Wrap All Conductors
- Material [MATT]
- Rubber Polychloroprene 1St Position Primary Insulation All Conductors
- Individual Conductor Length [CXGW]
- 0.875 Inches Nominal 2Nd End All Conductors
- Round Conductor Size [CXDC]
- 28 Awg All Conductors
- Overall Length [AAJU]
- 11.062 Inches
- Special Features [FEAT]
- Mil-C-5898C Type Wd-34/U Cord
- Strain Relief Style [CXGR]
- Staycord 2Nd End
- Strand Awg Size Per Conductor [CXDG]
- 40 All Conductors
- Strand Quantity Per Conductor [BLNZ]
- 19 All Conductors
- Surface Treatment [SFTT]
- Tin Core Conductor All Conductors
- Terminal Commercial And Government Entity Code [CXGN]
- 81349 1St End All Conductors
- Terminal Manufacturer Identifying Reference Number [CXGG]
- Mil-J-641/8D 1St End All Conductors
- Termination Type [AKRZ]
- Stripped 2Nd End All Conductors
- Termination Type [AKRZ]
- Jack Telephone 1St End All Conductors
DLA Procurement Analysis 5995-00-059-5179
Management Data 5995-00-059-5179
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5995-00-059-5179
Freight Information 5995-00-059-5179
5995-00-059-5179 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061130. A Sub NMFC of X. It has a NMFC Description of CABLE ASSEMBLY. 5995-00-059-5179 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34350 which rates the freight between FCL and LCL. 5995-00-059-5179 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 743 for ocean manifesting and military sealift. 5995-00-059-5179 is not classified as a special type of cargo when transported by water. 5995-00-059-5179 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5995-00-059-5179
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 5995-00-059-5179 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
