5990-01-041-3062
Control Transformer Synchro
5990010413062 010413062 18CX4A
A synchro consisting of a stator and rotor inductively coupled. The electrical output of the rotor is dependent upon both the position of the rotor and the electrical input to the stator from a transmitter synchro or a differential synchro. Does not include variable resistors, goniometers, or variable transformers. View more Control Transformer Synchro
May 2023
13
Marketplace 5990-01-041-3062
Request a Quotation from participating marketplace vendors
Related Documents 5990-01-041-3062 5+ Documents (More...)
5990-01-041-3062 (Identification) 5/5 - - - - - 1.
TRANSFORMER 1 EA NS Request Quotation Updated Every Day 5990-01-041-3062 RQST NE Related Documents 5990
18CX4A (AM9.0340.000.00) A synchro consisting of a stator and rotor inductively coupled.
Control Transformer Synchro 5990010413062 day Upgrade your Account Upgrade 5990-01-041-3062Control
/fsg-59/fsc-5990/us 5990-01-041-3062 Control Transformer Synchro 5990010413062 day Upgrade your Account
Upgrade 5990-01-041-3062Control Transformer Synchro5990010413062 010413062 18CX4A SYNCHRO,CONTROL TRANSFORMER
S20708-18CX4A 99062788 A synchro consisting of a stator and rotor inductively coupled.
Control Transformer Synchro 5990010413062 day Upgrade your Account Upgrade 5990-01-041-3062Control
https//www.nsnlookup.com /fsg-59/fsc-5990/us 5990-01-041-3062 Control Transformer Synchro 5990010413062
day Upgrade your Account Upgrade 5990-01-041-3062Control Transformer Synchro5990010413062 010413062
Restrictions 5990-01-041-3062
5990-01-041-3062 is a Control Transformer Synchro that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5990-01-041-3062
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5990-01-041-3062
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Jan 2000
Approved Sources 5990-01-041-3062
- Part Number
- Manufacturer
- Status
- 18CX4A
- Manufacturer
- A1911 - San Giorgio Elettrodomestici Spa (Active)
- Primary Buy
- Primary Buy
Datasheet 5990-01-041-3062
- Characteristic
- Specifications
- FIIG
- Specifications
- A07800
- Body Size [AJSL]
- 17
- Body Style [AAQL]
- Standard Round C
- Flange Diameter [ABKK]
- 39.6740 Millimeters Nominal
- Flange Thickness [ABKU]
- 2.3620 Millimeters Nominal
- Mounting Facility Screw Thread Series Designator [AKEJ]
- Unf
- Mounting Facility Nominal Screw Thread Diameter [CRYY]
- 0.112 Inches
- Securing Hole Quantity [AHYF]
- 3
- Shaft Diameter [ABWV]
- 4.755 Millimeters Nominal Single Shaft
- Shaft Length [ABXF]
- 12.697 Millimeters Nominal Single Shaft
- Shaft Nominal Thread Size [CWBH]
- 0.190 Inches Single Shaft
- Shaft Thread Class [AKAN]
- 2A
- Shaft Thread Direction [AKAF]
- Right-Hand Single Shaft
- Shaft Thread Length [CQWQ]
- 5.0800 Millimeters Nominal Single Shaft
- Shaft Type [CRSJ]
- Round, Threaded Single Shaft
- Shoulder Diameter [AAVH]
- 39.6740 Millimeters Nominal
- Shoulder Length [AJWR]
- 3.3520 Millimeters Nominal
- Overall Length [ABHP]
- 79.5510 Millimeters Nominal
- Pilot Diameter [AAVL]
- 23.8120 Millimeters Nominal
- Pilot Length [AJWQ]
- 2.0060 Millimeters Nominal
- Undercut Width [ABPC]
- 1.9810 Millimeters Nominal
- Terminal Location [CQTM]
- Rear
- Terminal Type And Quantity [TTQY]
- 6 Tab W/Screw
Similar Supply Items to 5990-01-041-3062
Freight Information 5990-01-041-3062
5990-01-041-3062 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 5990-01-041-3062 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5990-01-041-3062 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 590 for ocean manifesting and military sealift. 5990-01-041-3062 is not classified as a special type of cargo when transported by water. 5990-01-041-3062 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5990-01-041-3062
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 3.0" H x 3.0" W x 3.0" L
- --
- --
- --
- Any Suitable Process
- 3.0" H x 3.0" W x 3.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- Special requirement – See specific instructions or drawings provided
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
