5990-00-295-8205
Electrical Resolver
5990002958205 002958205 R232-2A L224486-1 A2542000410-0 23-112896-1 R232AA
An item consisting of a rotor and a stator inductively coupled. It usually has two rotor windings displaced from each other by 90 degrees and two stator windings similarly displaced. The output voltage(s) is a trigonometric function of the input voltage(s) and the angular displacement of the rotor with respect to the stator. See also SYNCHRO (as modified) and GONIOMETER, ELECTRICAL. Excludes TRANSOLVER, ELECTRICAL and potentiometer sine/cosine electrical resolvers. View more Electrical Resolver
May 2023
15
Marketplace 5990-00-295-8205
Request a Quotation from participating marketplace vendors
Related Documents 5990-00-295-8205 1+ Documents (More...)
RQST NE Updated Every Day 5990-00-295-8205 RQST Updated Every Day 5990-00-295-8205 RQST NE Related Documents
5990-00-295-8205 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5990/us 5990-00-295-8205
Restrictions 5990-00-295-8205
5990-00-295-8205 is a Electrical Resolver that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5990-00-295-8205
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5990-00-295-8205
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
Approved Sources 5990-00-295-8205
- Part Number
- Manufacturer
- Status
- R232-2A
- Manufacturer
- 88818 - Kearfott Corporation (Active)
- Primary Buy
- Primary Buy
- L224486-1
- 06845 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- A2542000410-0
- 89944 - Elbitamerica, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 23-112896-1
- 94923 - Gte Products Corp Entertainment (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- R232AA
- 94923 - Gte Products Corp Entertainment (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5990-00-295-8205
- Characteristic
- Specifications
- FIIG
- Specifications
- A07800
- Body Material [AAFZ]
- Steel, Corrosion Resisting
- Body Size [AJSL]
- 11
- Flange Diameter [ABKK]
- 1.0620 Inches Nominal
- Frequency In Hertz [AJSS]
- 400.0 Nominal
- Rotor Input Voltage Rating In Volts [AJSR]
- 26.0 Maximum
- Shaft Diameter [ABWV]
- 0.1200 Inches Nominal Single Shaft
- Shaft Slot Depth [CQZS]
- 0.0300 Inches Nominal Single Shaft
- Shaft Slot Width [CRHN]
- 0.0250 Inches Nominal Single Shaft
- Shaft Type [CRSJ]
- Round, Slotted Single Shaft
- Shaft Length [ABXF]
- 0.4530 Inches Nominal Single Shaft
- Overall Length [ABHP]
- 3.1560 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 6 Wire Lead
Similar Supply Items to 5990-00-295-8205
Freight Information 5990-00-295-8205
5990-00-295-8205 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 5990-00-295-8205 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 5990-00-295-8205 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 5990-00-295-8205 is not classified as a special type of cargo when transported by water. 5990-00-295-8205 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5990-00-295-8205
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-P-130, Laminated and Creped Wrapping Paper
- A-A-1051, Paperboard Cushioning
- --
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- MIL-P-130, Laminated and Creped Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
