5985-01-560-7417
Antenna
5985015607417 015607417 OD24-9
An item consisting of a conductor or a system of conductors specifically designed to radiate and/or receive electromagnetic waves in free space. May include beam-forming devices, drive motors, synchros, radome, and associated mechanical structure. View more Antenna
May 2023
2
Marketplace 5985-01-560-7417
Request a Quotation from participating marketplace vendors
Related Documents 5985-01-560-7417 5+ Documents (More...)
/fsg-59/fsc-5985/us
United States (US) 4. 5985-01-560-7417 Marketplace Restrictions Approved Sources Datasheet Management
/fsc-5985/us 5985-01-560-7417 Antenna 5985015607417015607417,OD24-9 OD24-9 An item consisting of a conductor
/fsg-59/fsc-5985/uk
Restrictions 5985-01-560-7417
5985-01-560-7417 is a Antenna that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5985-01-560-7417
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5985-01-560-7417
- Spain (YB01)
- Effective Date:
- 1 Feb 2008
Approved Sources 5985-01-560-7417
- Part Number
- Manufacturer
- Status
- OD24-9
- Manufacturer
- 32ZR6 - Cushcraft Corporation Dba Pacific (Active)
- Primary Buy
- Primary Buy
Datasheet 5985-01-560-7417
- Characteristic
- Specifications
- FIIG
- Specifications
- A074A0
- Special Features [FEAT]
- 9Dbi Gain, Vertical Beam Width 14 Degree, Electrical Downtilt 0 Deg Or 7 Deg, Rated Wind Velocity 125Mph. Weight 1.15 Lbs, Dimension 27 Inches. Frequency Range 2400 Min 2485 Max, Input Return Loss -14, Vswr 1:5:1, 50 Ohm Impedance, Input Power 100W. Opertaing Temp -40 To +70 Degree C. Type N Female Integrated Bulkhead Connector
Similar Supply Items to 5985-01-560-7417
Freight Information 5985-01-560-7417
5985-01-560-7417 has freight characteristics.. 5985-01-560-7417 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
