5985-01-319-4977

Radio Frequency Transmission Line Switch

5985013194977 013194977 581R529H08 2669-9015

An item specifically designed for mechanically or electronically positioning one or more radio frequency transmission line sections so as to couple it or them to other sections in a radio frequency transmission line system. The switching function may be operated by a manual actuator, an electromechanical actuator or by means of an arrangement of semiconductors and passive circuit devices. Excludes RELAY, (as modified). View more Radio Frequency Transmission Line Switch

Managed by United States

NSN Created on 9 May 1990

Data Last Changed
May 2023

NATO Update Count
7

NATO Data Quality

5985-01-319-4977 SWITCH,RADIO FREQUENCY TRANSMISSION LINE 5985013194977 013194977 1/2 — 5985-01-319-4977 Photo 1/2

AAQL Style 15B for 5985-01-319-4977 2/2 — NSN 5985-01-319-4977 (Identification) 2/2

Marketplace 5985-01-319-4977

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

5985-01-319-4977 RQST NE

Restrictions 5985-01-319-4977

IUID Required

5985-01-319-4977 is a Radio Frequency Transmission Line Switch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 5985-01-319-4977

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5985-01-319-4977

US Air Force (FGG4)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AMSC F IMC E IMCACTY TG DSOR FR

Belgium (ZB01)
Effective Date:: 1 Feb 1998

Approved Sources 5985-01-319-4977

Part Number
Manufacturer
Status
581R529H08: 97942 - Northrop Grumman Systems Corporation (Active); Primary Buy; RNCC 3 RNVC 2 DAC 2
2669-9015: 96341 - Cobham Advanced Electronic Solutions (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5

Datasheet 5985-01-319-4977

Characteristic
Specifications
FIIG: A158A0
Switch Type [AEEA]: Nontransfer
Pole Quantity [AKPX]: 1
Throw Quantity [AKPY]: 3
Coupling Position Quantity [AKRC]: 3
Terminal Type And Quantity [TTQY]: 4 Connector, Receptacle
Body Style [AAQL]: Irregular
Overall Length [ABHP]: 1.500 Inches Nominal
End Item Identification [AGAV]: Alq-131 2Band Pod
