5985-01-042-0592
Waveguide Assembly
5985010420592 010420592 58-P01630H001
An item consisting of one or more definite lengths of straight or formed, flexible or rigid, prefabricated hollow tubing of conductive material. The tubing has a predetermined cross section and is designed to guide or conduct high frequency electromagnetic energy through its interior. One or more ends are terminated. May include common mounting of a SWITCH, WAVE GUIDE, a DUMMY LOAD, ELECTRICAL and other components such as waveguide section, cable terminal chamber and the like. Excludes COUPLER, ROTARY, RADIO FREQUENCY; COUPLER, DIRECTIONAL; ADAPTER, WAVEGUIDE; and TUNER, WAVEGUIDE. View more Waveguide Assembly
May 2023
4
Marketplace 5985-01-042-0592
Request a Quotation from participating marketplace vendors
Related Documents 5985-01-042-0592 1+ Documents (More...)
BUY NE FedMall Updated Every Day 5985-01-042-0592 RQST NE Updated Every Day 5985-01-042-0592 RQST
Updated Every Day 5985-01-042-0592 RQST NE Related Documents 5985-01-042-0592 1+ Documents ( More...
Restrictions 5985-01-042-0592
5985-01-042-0592 is a Waveguide Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5985-01-042-0592
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5985-01-042-0592
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
Approved Sources 5985-01-042-0592
- Part Number
- Manufacturer
- Status
- 58-P01630H001
- Manufacturer
- 1VPW8 - General Dynamics Mission Systems, (Active)
- Primary Buy
- Primary Buy
- 58-P01630H001
- 94990 - Motorola Inc. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5985-01-042-0592
- Characteristic
- Specifications
- FIIG
- Specifications
- A073A0
- Bend Angle In Deg [ACJL]
- 90.0 Single Bend H-Plane
- Flange Quantity [AHSF]
- 2
- Flexibility [FLEX]
- Rigid Single Tubing Segment
- Material [MATT]
- Aluminum Alloy 1100 Single Tubing Segment
- Style Designator [STYL]
- Elbow Type
- Insertion Loss In Decibels [AHTX]
- 0.30
- Voltage Standing Wave Ratio [AHTW]
- 1.05
- Waveguide Longer Offset Distance [CSPL]
- 8.500 Inches Nominal
- Waveguide Offset Distance [CWBG]
- 2.310 Inches Nominal
- Surface Treatment [SFTT]
- Passivate All Tubing Segment And Flange Outside Surfaces And Primer All Tubing Segment And Flange Outside Surfaces And Plastic All Tubing Segment And Flange Outside Surfaces
DLA Procurement Analysis 5985-01-042-0592
Management Data 5985-01-042-0592
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5985-01-042-0592
Freight Information 5985-01-042-0592
5985-01-042-0592 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 063520. A Sub NMFC of Z. It has a NMFC Description of WAVEGUIDE IN BOXES/CRATES. 5985-01-042-0592 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49770 which rates the freight between FCL and LCL. 5985-01-042-0592 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5985-01-042-0592 is not classified as a special type of cargo when transported by water. 5985-01-042-0592 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5985-01-042-0592
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5985-01-042-0592 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
