5985-01-038-6694
Variable Attenuator
5985010386694 010386694 10186097 ARS-1/21982
A device for reducing the strength of an alternating current signal either continuously or in steps, without causing appreciable signal distortion, by maintaining substantially constant output and/or input impedance match. Continuously variable resistive devices must consist of at least two sections or one section with at least two rotating contacts. The item must have an overall attenuation rating. Includes tandem mounted variable resistors designed to function as an attenuator but whose terminals are not connected. See also RESISTOR, VAIABLE (as modified). View more Variable Attenuator
May 2023
13
Marketplace 5985-01-038-6694
Request a Quotation from participating marketplace vendors
Related Documents 5985-01-038-6694 1+ Documents (More...)
Photo 1/9 5985-01-038-6694 Photo 2/9 5985-01-038-6694 Photo 3/9 5985-01-038-6694 Photo 4/9 5985
-01-038-6694 Photo 5/9 5985-01-038-6694 Photo 6/9 5985-01-038-6694 Photo 7/9 5985-01-038-6694 Photo 8
Restrictions 5985-01-038-6694
5985-01-038-6694 is a Variable Attenuator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5985-01-038-6694
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5985-01-038-6694
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
Approved Sources 5985-01-038-6694
- Part Number
- Manufacturer
- Status
- 10186097
- Manufacturer
- 18876 - Us Army Aviation And Missile Command (Active)
- Primary Buy
- Primary Buy
- ARS-1/21982
- 12457 - Merrimac Industries Inc (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5985-01-038-6694
- Characteristic
- Specifications
- FIIG
- Specifications
- A223A0
- Adjustment Device Type And Quantity [CQTQ]
- 1 Slotted Screw
- Attenuation Variation Method [ASYF]
- Continuous
- Body Style [AAQL]
- Coaxial Type
- Frequency Range [BNGR]
- 0.000 Megahertz Minimum And 200.000 Megahertz Maximum
- Application Design [AAFS]
- Transmission Line
- Mounting Facility Type And Quantity [AXHR]
- 2 Terminal
- Operating Temp Range [AFGA]
- -29.0/+52.0 Deg Celsius
- Impedance Rating In Ohms [CTGG]
- 50.0 Input-Output
- Insertion Loss At Minimum Attenuation In Maximum Decibels [ASYC]
- 1.5
- Power Rating [AJDB]
- 500.0 Milliwatts Average
- Overall Attenuation Range In Decibels [ASYD]
- +0.0/+15.0
- Overall Height [ABKW]
- 0.750 Inches Nominal
- Overall Length [ABHP]
- 1.450 Inches Nominal
- Overall Width [ABMK]
- 0.750 Inches Nominal
- Voltage Standing Wave Ratio [AHTW]
- 1.50
- Terminal Type And Quantity [TTQY]
- 4 Pin
DLA Procurement Analysis 5985-01-038-6694
Management Data 5985-01-038-6694
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5985-01-038-6694
Freight Information 5985-01-038-6694
5985-01-038-6694 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of X. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5985-01-038-6694 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 5985-01-038-6694 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5985-01-038-6694 is not classified as a special type of cargo when transported by water. 5985-01-038-6694 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
