5985-01-037-2214
Directional Coupler
5985010372214 010372214 426/4/02007/002 2020-6601-10 2020-6601
An item specifically designed to be inserted into a transmission line, waveguide or coaxial transmission line to provide a suitable test outlet. The test signal is attenuated to a predetermined value. View more Directional Coupler
May 2023
10
Marketplace 5985-01-037-2214
Request a Quotation from participating marketplace vendors
Updated Every 15 Minutes
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5985-01-037-2214 5+ Documents (More...)
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 2020-6601
-10 COUPLER,DIRECTIONAL 1 EA NS Request Quotation Subscribe to View Vendor Details... 2020-6601-10
Restrictions 5985-01-037-2214
5985-01-037-2214 is a Directional Coupler that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5985-01-037-2214
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5985-01-037-2214
- US Air Force (FXGX)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- FXTX
Approved Sources 5985-01-037-2214
- Part Number
- Manufacturer
- Status
- 2020-6601-10
- Manufacturer
- 96341 - Cobham Advanced Electronic Solutions (Obsolete)
- Original Design
- Original Design
- 426/4/02007/002
- U2982 - Bae Systems (Defence Systems) Ltd (Active)
- Secondary Buy
- Secondary Buy
- 2020-6601
- 96341 - Cobham Advanced Electronic Solutions (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5985-01-037-2214
- Characteristic
- Specifications
- FIIG
- Specifications
- T389-C
- Design Type [APGF]
- Bidirectional
- Fsc Application Data [ZZZV]
- Antennas,Waveguides,And Related Equipment
- Power Loss In Decibels [BGPX]
- 10.0
- Radio Frequency Rating [ANKZ]
- 0.5 Gigahertz Minimum And 1.0 Gigahertz Maximum
- Overall Height [ABKW]
- 0.375 Inches Nominal
- Overall Length [ABHP]
- 1.750 Inches Nominal
- Overall Width [ABMK]
- 1.014 Inches Nominal
- Unit Type [APQB]
- Transmission Line
- Unpackaged Unit Weight [AWJN]
- 1.500 Ounces
- Voltage Standing Wave Ratio At Reference Frequency [BGPS]
- 1.1 To 1 At 0.5 To 1 Ghz
- Terminal Fitting Controlling Agency [BGPZ]
- Mil
- Terminal Fitting Name [BGPY]
- Connector Receptacle
- Terminal Fitting Usage Design [BGQC]
- Main Line
Weapon Systems (WSDC) 5985-01-037-2214
DLA Procurement Analysis 5985-01-037-2214
Management Data 5985-01-037-2214
Similar Supply Items to 5985-01-037-2214
Freight Information 5985-01-037-2214
5985-01-037-2214 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061520. A Sub NMFC of X. It has a NMFC Description of COUPLINGS CONDUIT CAST IRON. 5985-01-037-2214 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34460 which rates the freight between FCL and LCL. 5985-01-037-2214 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5985-01-037-2214 is not classified as a special type of cargo when transported by water. 5985-01-037-2214 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5985-01-037-2214
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5985-01-037-2214 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
