5985-01-037-1724
Fixed Attenuator
5985010371724 010371724 SM-A-731339-1 50SP6TNC RMAT6.2000TNCFFD AFA06TB
A device for reducing the strength of an alternating current signal by a fixed or predetermined amount, without causing appreciable signal distortion, by maintaining correct impedance match. View more Fixed Attenuator
November 2023
15
Marketplace 5985-01-037-1724
Request a Quotation from participating marketplace vendors
Related Documents 5985-01-037-1724 4+ Documents (More...)
Photo 1/3 5985-01-037-1724 Photo 2/3 NSN 5985-01-037-1724 (Identification) 3/3 - - - 1.
BUY NE FedMall Updated Every Day 5985-01-037-1724 RQST NE Related Documents 5985-01-037-1724 1+
Restrictions 5985-01-037-1724
5985-01-037-1724 is a Fixed Attenuator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.
Import and Export 5985-01-037-1724
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5985-01-037-1724
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- CL
- MOE Rule:
- BGX1
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- BTX1
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXTX
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Supplementary Collaborators:
- HD
Approved Sources 5985-01-037-1724
- Part Number
- Manufacturer
- Status
- SM-A-731339-1
- Manufacturer
- 80063 - Us Army Communications & Electronics (Active)
- Primary Buy
- Primary Buy
- 50SP6TNC
- 52750 - Alan Industries Inc (Active)
- Secondary Buy
- Secondary Buy
- SM-A-731339-1
- 91417 - L3harris Technologies, Inc. (Active)
- Secondary Buy
- Secondary Buy
- RMAT6.2000TNCFFD
- 3DAV8 - Response Microwave, Inc. (Active)
- Secondary Buy
- Secondary Buy
- SM-A-731339-1
- 3DAV8 - Response Microwave, Inc. (Active)
- Secondary Buy
- Secondary Buy
- SM-A-731339-1
- 66702 - Coaxial Components Corp. (Active)
- Secondary Buy
- Secondary Buy
- AFA06TB
- 53908 - Computer Automation Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- AFA06TB
- 0PW72 - Bae Systems Aerospace Electronics (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5985-01-037-1724
- Characteristic
- Specifications
- FIIG
- Specifications
- A20000
- Application Design [AAFS]
- Transmission Line
- Attenuation Accuracy In Decibels [ASYN]
- -0.50/+0.50
- Body Material [AAFZ]
- Brass
- Body Style [AAQL]
- Round, Terminal/Terminals In Opposite Surface
- Body Surface Treatment [ABEM]
- Silver Plated
- Coaxial Connector Series Designation [AHUC]
- Tnc
- Connection Type Per Function [ASZN]
- Female Output And Male Input
- Frequency Range [BNGR]
- 0.000 Hertz Minimum And 1.000 Gigahertz Maximum
- Mounting Method [AXGY]
- Connector
- Output Impedance Rating In Ohms [AHTZ]
- 50.0
- Input Impedance Rating In Ohms [AHTY]
- 50.0
- Power Rating [AJDB]
- 1.0 Watts Average
- Precious Material And Location [PMLC]
- Body Silver
- Precious Material [PRMT]
- Silver
- Rf Signal Attenuation In Decibels [AJDK]
- 6.0
- Overall Diameter [ADAV]
- 0.850 Inches Nominal
- Overall Length [ABHP]
- 2.030 Inches Nominal
- Voltage Standing Wave Ratio Frequency Range [AKNK]
- +0.0/+100.0 Megahertz And +0.100/+1.000 Gigahertz
- Voltage Standing Wave Ratio [AHTW]
- 1.05 And 1.20
- Terminal Type And Quantity [BBHS]
- 2 Connector
DLA Procurement Analysis 5985-01-037-1724
- Last Stock Position:
- 21 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5985-01-037-1724
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 4V
- Communications System Agency and Satellite Communications Agency Equipment
Baseband Satellite Communication
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5985-01-037-1724
Freight Information 5985-01-037-1724
5985-01-037-1724 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 060535. A Sub NMFC of Z. It has a NMFC Description of AERIAL/ANTENNAS DIRECTIONAL. 5985-01-037-1724 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 06330 which rates the freight between FCL and LCL. 5985-01-037-1724 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5985-01-037-1724 is not classified as a special type of cargo when transported by water. 5985-01-037-1724 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5985-01-037-1724
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- --
- --
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
