5985-00-449-9239
Fixed Attenuator
5985004499239 004499239 61711 602 2132514-1 2132514
A device for reducing the strength of an alternating current signal by a fixed or predetermined amount, without causing appreciable signal distortion, by maintaining correct impedance match. View more Fixed Attenuator
May 2023
5
Marketplace 5985-00-449-9239
Request a Quotation from participating marketplace vendors
Related Documents 5985-00-449-9239 5+ Documents (More...)
Vendor Details... 602 ATTENUATOR,FIXED RQST NS Request Quotation FedMall Updated Every 15 Minutes 5985
-00-449-9239 BUY NE FedMall Updated Every Day 5985-00-449-9239 RQST NE Updated Every Day 5985-00-449-
Day 2520-15-143-6976 RQST NE Related Documents https//www.nsnlookup.com /fsg-59/fsc-5985/us 5985-00-449-9239
Fixed Attenuator 5985004499239 004499239 day Upgrade your Account Upgrade 5985-00-449-9239Fixed
fsg-61/fsc-6125/fr 6125-14-209-8369 Differentiel Et Arb 6125142098369 142098369 016146458,61711 003 61711
$1 a day Upgrade your Account Upgrade 6615-00-569-2780Motor Extension6615005692780 005692780S1565-61711
Account Upgrade 7643-01-401-7518Topographic Geospatial Products7643014017518 014017518E733X61711E733 61711
Fixed Attenuator 5985004499239 004499239 2780Motor Extension6615005692780 005692780S1565-61711
-003 61711-001 M-F61711-001 PL 61711-002 IT1 A microphone which depends for its operation upon the generation
-001M-F61711-001PL 61711-002 IT1 A https enable M-F61711-001PL 61711-002 IT1 A microphone which depends
Restrictions 5985-00-449-9239
5985-00-449-9239 is a Fixed Attenuator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5985-00-449-9239
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5985-00-449-9239
- US Air Force (FGGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FGTX
Approved Sources 5985-00-449-9239
- Part Number
- Manufacturer
- Status
- 61711
- Manufacturer
- 00443 - Waveline Inc (Active)
- Primary Buy
- Primary Buy
- 602
- 00443 - Waveline Inc (Active)
- Secondary Buy
- Secondary Buy
- 2132514-1
- 55974 - Honeywell Intl Inc (Active)
- Vendor Drawing
- Vendor Drawing
- 2132514
- 19315 - Honeywell Intl Inc Defense Avionics (Active)
- Informational Drawing
- Informational Drawing
Datasheet 5985-00-449-9239
- Characteristic
- Specifications
- FIIG
- Specifications
- A20000
- Application Design [AAFS]
- Waveguide
- Attenuation Accuracy In Decibels [ASYN]
- -0.50/+0.50
- Body Style [AAQL]
- Round,Terminal/Terminals On Opposite Surfaces
- Frequency Range [BNGR]
- 8.200 Gigahertz Minimum And 12.400 Gigahertz Maximum
- Mounting Hole/Stud Quantity [ADAE]
- 4
- Mounting Method [AXGY]
- Terminal W/Mounting Holes
- Operating Temp Range [AFGA]
- +0.0/+71.0 Deg Celsius
- Power Rating [AJDB]
- 15.0 Watts Average And 30.0 Watts Peak
- Rf Signal Attenuation In Decibels [AJDK]
- 30.0
- Overall Diameter [ADAV]
- 2.370 Inches Nominal
- Overall Length [ABHP]
- 9.880 Inches Nominal
- Voltage Standing Wave Ratio [AHTW]
- 1.15
- Waveguide Flange Designation [AKSA]
- Ug-135/U
- Waveguide Flange Type [AKPT]
- Cover
- Terminal Type And Quantity [BBHS]
- 2 Flange
Weapon Systems (WSDC) 5985-00-449-9239
DLA Procurement Analysis 5985-00-449-9239
Management Data 5985-00-449-9239
Similar Supply Items to 5985-00-449-9239
Freight Information 5985-00-449-9239
5985-00-449-9239 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 060535. A Sub NMFC of Z. It has a NMFC Description of AERIAL/ANTENNAS DIRECTIONAL. 5985-00-449-9239 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 06330 which rates the freight between FCL and LCL. 5985-00-449-9239 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5985-00-449-9239 is not classified as a special type of cargo when transported by water. 5985-00-449-9239 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
