5985-00-271-9502

Waveguide Assembly

5985002719502 002719502 SMC730413

An item consisting of one or more definite lengths of straight or formed, flexible or rigid, prefabricated hollow tubing of conductive material. The tubing has a predetermined cross section and is designed to guide or conduct high frequency electromagnetic energy through its interior. One or more ends are terminated. May include common mounting of a SWITCH, WAVE GUIDE, a DUMMY LOAD, ELECTRICAL and other components such as waveguide section, cable terminal chamber and the like. Excludes COUPLER, ROTARY, RADIO FREQUENCY; COUPLER, DIRECTIONAL; ADAPTER, WAVEGUIDE; and TUNER, WAVEGUIDE. View more Waveguide Assembly

Managed by United States

NSN Created on 25 Jul 1973

Data Last Changed
May 2023

NATO Update Count
4

NATO Data Quality

5985-00-271-9502 WAVEGUIDE ASSEMBLY 5985002719502 002719502 1/3 — 5985-00-271-9502 Photo 1/3

AAGR Style A1 for 5985-00-271-9502 2/3 — NSN 5985-00-271-9502 (Identification) 2/3

STYL Style B3 for 5985-00-271-9502 3/3 — NSN 5985-00-271-9502 (Identification) 3/3

Marketplace 5985-00-271-9502

Need Help?
Request a Quotation from participating marketplace vendors

FedMall

Updated Every 15 Minutes

5985-00-271-9502 BUY NE FedMall

Updated Every Day

5985-00-271-9502 RQST NE

Restrictions 5985-00-271-9502

5985-00-271-9502 is a Waveguide Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains Silver.

Import and Export 5985-00-271-9502

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5985-00-271-9502

US Army (A918)
Effective Date:: 1 Apr 2006
Former MOE Rule:: A196
Supplementary Receivers:: CL; AMC 0 AMSC 0 IMC Z IMCACTY CL

Approved Sources 5985-00-271-9502

Part Number
Manufacturer
Status
SMC730413: 80063 - Us Army Communications & Electronics (Active); Primary Buy; RNCC 3 RNVC 2 DAC 1

Datasheet 5985-00-271-9502

Characteristic
Specifications
FIIG: A073A0
Bend Angle In Deg [ACJL]: 90.0 Single Bend H-Plane
Cross-Sectional Shape Style [AAGR]: Internal, Rectangular External, Rectangular
Flange Depth [AHTD]: 0.250 Inches Nominal Second Flange
Flange Depth [AHTD]: 0.250 Inches Nominal First Flange
Flange Connecting Facility And Quantity [CSQT]: 4 Unthreaded Hole First Flange Single Connection Facility
Flange Connecting Facility And Quantity [CSQT]: 4 Unthreaded Hole Second Flange Single Connection Facility
Flange Connecting Hole Diameter [AHTN]: 0.116 Inches Nominal First Flange Single Connection Facility
Flange Connecting Hole Diameter [AHTN]: 0.120 Inches Nominal Second Flange Single Connection Facility
Flange Inside Height [AHSY]: 0.194 Inches Nominal First Flange
Flange Inside Height [AHSY]: 0.194 Inches Nominal Second Flange
Flange Inside Width [AHSX]: 0.223 Inches Nominal First Flange
Flange Inside Width [AHSX]: 0.223 Inches Nominal Second Flange
Flange Quantity [AHSF]: 2
Flange Style [CTCJ]: Choke Type First Flange
Flange Style [CTCJ]: Cover Type Second Flange
Flange Outside Height [AHTA]: 0.750 Inches Nominal First Flange
Flange Outside Height [AHTA]: 0.750 Inches Nominal Second Flange
Flange Outside Width [AHSZ]: 0.750 Inches Nominal First Flange
Flange Outside Width [AHSZ]: 0.750 Inches Nominal Second Flange
Flexibility [FLEX]: Rigid Single Tubing Segment
Fsc Application Data [ZZZV]: Satellite Communication Terminal An/Msc-46V
Material [MATT]: Silver Alloy All Flange
Style Designator [STYL]: Corner Type
Tubing Wall Construction Style [AHRV]: Seamless Single Tubing Segment
Waveguide Inside Height [CRLB]: 0.111 Inches Minimum And 0.113 Inches Maximum
Waveguide Offset Distance [CWBG]: 1.125 Inches Nominal
Waveguide Outside Height [CSFC]: 0.190 Inches Minimum And 0.194 Inches Maximum
Waveguide Outside Width [CQHN]: 0.302 Inches Minimum And 0.306 Inches Maximum
Waveguide Inside Width [CRFH]: 0.223 Inches Minimum And 0.225 Inches Maximum
Waveguide Longer Offset Distance [CSPL]: 1.750 Inches Nominal
Surface Treatment [SFTT]: Enamel All Flange Outside Surfaces

Subscribe
View Data

DLA Procurement Analysis 5985-00-271-9502

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5985-00-271-9502

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Mar 2023: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Defense Logistics Agency (DS): I; X; Formerly 5895

Army

Materiel Category and Inventory Manager:

Q: Electronics Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Similar Supply Items to 5985-00-271-9502

Freight Information 5985-00-271-9502

5985-00-271-9502 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063520. A Sub NMFC of Z. It has a NMFC Description of WAVEGUIDE IN BOXES/CRATES. 5985-00-271-9502 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49770 which rates the freight between FCL and LCL. 5985-00-271-9502 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5985-00-271-9502 is not classified as a special type of cargo when transported by water. 5985-00-271-9502 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5985-00-271-9502

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"; 85 to 110G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Contracting Technical Data File (CTDF) 5985-00-271-9502 October 2021
