5985-00-058-7685
Antenna Stop
5985000587685 000587685 G6771-023
An item designed to check the movement or action of an antenna. Do not use if a more specific item name appears in this index. View more Antenna Stop
May 2023
11
Marketplace 5985-00-058-7685
Request a Quotation from participating marketplace vendors
Related Documents 5985-00-058-7685 1+ Documents (More...)
G6771-023 STOP 3 EA NS Request Quotation Updated Every Day 5985-00-058-7685 RQST NE Updated Every Day
5985-00-058-7685 RQST Updated Every Day 5985-00-058-7685 RQST NE Related Documents 5985-00-058-7685
Restrictions 5985-00-058-7685
5985-00-058-7685 is a Antenna Stop that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5985-00-058-7685
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5985-00-058-7685
- Brazil (YA01)
- Effective Date:
- 1 Jan 2011
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5985-00-058-7685
- Part Number
- Manufacturer
- Status
- G6771-023
- Manufacturer
- 81413 - Bae Systems Information And (Active)
- Primary Buy
- Primary Buy
Datasheet 5985-00-058-7685
- Characteristic
- Specifications
- FIIG
- Specifications
- A12000
- Basic Shape Style [AGTA]
- L-Shape
- Material [MATT]
- Aluminum
- Mounting Facility Quantity [AKPV]
- 1
- Mounting Hole Diameter [ABTB]
- 0.199 Inches Nominal
- Mounting Hole Type [ACHY]
- Plain
- Mounting Method [ADJH]
- Unthreaded Holes
- Overall Height [ABKW]
- 0.580 Inches Nominal
- Overall Length [ABHP]
- 1.040 Inches Nominal
- Overall Width [ABMK]
- 0.780 Inches Nominal
Similar Supply Items to 5985-00-058-7685
Freight Information 5985-00-058-7685
5985-00-058-7685 has freight characteristics managed by the General Services Administration (GSA).It has a National Motor Freight Classification (NMFC) of 013120. A Sub NMFC of F. It has a NMFC Description of ALUMINUM ARTICLE NOI SUB 6. 5985-00-058-7685 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05380 which rates the freight between FCL and LCL. 5985-00-058-7685 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5985-00-058-7685 is not classified as a special type of cargo when transported by water. 5985-00-058-7685 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5985-00-058-7685
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
