5977-00-928-6147

Electrical Contact Brush

5977009286147 009286147 32530 50AX147 5741291 74629 71128 945866

An item specifically designed to be used in the transfer of electrical energy to or from another conducting surface. Either the brush or the surface is continually moving during the transfer of energy. The brush is usually composed in part of some form of the element carbon. Includes: (1) a single brush either with or without an attached shunt (flexible wire lead) and/or a helical or flat type pressure spring; (2) a split brush composed of two or more pieces (wafers), which are used in place of one brush usually connected together by individual shunts to a common terminal; (3) paired brushes composed of two identical or non-identical brushes connected together by a common shunt either with or without pressure springs or connected by individual shunts to a common terminal, or with pressure springs and connected to a common bar, bracket or the like either with or without individual shunts; (4) multiple brushes composed of more than two identical or non-identical brushes without pressure springs connected by individual shunts to a common terminal, or with pressure springs and connected to a common bar, bracket or the like by individual shunts. Does not include moving contacts which make and slide past stationary contacts, but are stationary while the circuit is conducting, such as the sliding contacts on a rheostat or the stationary contact on a synchro. Excludes: CONTACT, ELECTRICAL; and CONTACT ASSEMBLY, ELECTRICAL. View more Electrical Contact Brush

5977-00-928-6147 BRUSH,ELECTRICAL CONTACT 5977009286147 009286147

Managed by United States
NSN Created on 26 Aug 1966
Data Last Changed
November 2023
NATO Update Count
48
NATO Data Quality
AAQL Style B1 for 5977-00-928-6147 1/3
NSN 5977-00-928-6147 (Identification) 1/3
CQGT Style D5 for 5977-00-928-6147 2/3
NSN 5977-00-928-6147 (Identification) 2/3
STYL Style A1 for 5977-00-928-6147 3/3
NSN 5977-00-928-6147 (Identification) 3/3

5977-00-928-6147 Stock and Availability Marketplace 5977-00-928-6147

Need Help?
Request a Quotation from participating marketplace vendors

5977-00-928-6147 Related Documents Related Documents 5977-00-928-6147 5+ Documents (More...)

7644-01-574-1291 7644015741291 015741291 is a digital map, chart, or geodetic product, distributed, or not, by the defense mapping agency, which is associated with air and/or water and/or land navigation, tracking, and charting.
with the Cage Code 74629.
What is CAGE Code 74629?
74629 refers to Sisters Of The Good Sheperd Altar Bread Dept located at , Baltimore MD 21200, United
6110-99-574-1291 6110995741291 995741291 is a device operated by electromechanical means which functions to bring to rest mechanically and/or hold at rest a load.
8135-14-574-1291 8135145741291 145741291 is a natural or synthetic material in the form of a resilient mass. it may be bulk material or may be molded or cut to predetermined dimensions; bound with any suitable material, such as elastic; used to protect items against vibrational shocks, impact shocks, and abrasion, for filling in packaging, and for absorbing liquids from containers broken in transit. for corrugated items, see fiberboard, corrugated. excludes insert, packaging. do not use if a more specific item name is applicable.

5977-00-928-6147 Demil Restrictions 5977-00-928-6147

DEMIL: A | DEMILI: 1 | CRITICALITY: X | HMIC: N | PMIC: U | EDC: | ADPEC:

5977-00-928-6147 is a Electrical Contact Brush that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

5977-00-928-6147 HTS and ScheduleB Import and Export 5977-00-928-6147

5977-00-928-6147 End Users End Users 5977-00-928-6147

US Army (A918)
Effective Date:
1 Sep 2006
Former MOE Rule:
A178
Supplementary Receivers:
AZBD
US Air Force (FXGG)
Effective Date:
1 Sep 2006
Former MOE Rule:
FXCX
NASA (G860)
Effective Date:
1 Jun 1998
US Marine Corps (MC41)
Effective Date:
1 Sep 2006
Former MOE Rule:
MC04
US Navy (N9BG)
Effective Date:
1 Sep 2006
Former MOE Rule:
NIGD
Supplementary Collaborators:
GTKEHD
Lithuania (WI01)
Effective Date:
1 Jul 2001
Brazil (YA01)
Effective Date:
1 Jan 2002
Spain (YB01)
Effective Date:
1 Mar 1999
Israel (YD01)
Effective Date:
1 Sep 2016
Kuwait (YK01)
Effective Date:
1 Feb 2015
Morocco (YP01)
Effective Date:
1 Apr 2017
Canada (ZC01)
Effective Date:
1 Apr 1991
New Zealand (ZE01)
Effective Date:
1 Apr 1991
France (ZF01)
Effective Date:
1 May 2015
Germany (ZG01)
Effective Date:
1 Apr 1991
Republic of Korea (ZH01)
Effective Date:
1 Apr 1991
Portugal (ZP01)
Effective Date:
1 Jul 2010
Norway (ZT01)
Effective Date:
1 Apr 1991
Greece (ZU01)
Effective Date:
1 Jun 1995
Turkey (ZW01)
Effective Date:
1 Nov 2005

5977-00-928-6147 Manufacturers Approved Sources 5977-00-928-6147

5977-00-928-6147 Technical Data Datasheet 5977-00-928-6147

Characteristic
Specifications
FIIG
A01500
Body Style [AAQL]
Cylindrical
Brush Shunt Length [AHXP]
1.500 Inches Nominal Single Shunt
Contact Face Style [CQGT]
Flat
Diameter [ABMZ]
0.312 Inches Nominal
Material Document And Classification [MDCL]
Morganite Carbon Grade Cm-5H Mfr Ref Single Material Response
Material [MATT]
Carbon
Length [ABRY]
0.562 Inches Nominal
Pressure Spring Type And Quantity [CRWQ]
1 Cylindrical
Shunt Insulation Provision And Quantity [CRBG]
1 Uninsulated
Shunt Position Designator [AABU]
5
Style Designator [STYL]
One Piece
Terminal Diameter [AEBT]
0.281 Inches Nominal
Terminal Type And Quantity [TTQY]
1 Round Cap

5977-00-928-6147 Weapon Systems (WSDC) Weapon Systems (WSDC) 5977-00-928-6147

5977-00-928-6147 Stock, Inventory and Procurement DLA Procurement Analysis 5977-00-928-6147

Last Stock Position:
31 In Stock
DLA Administrative Lead Time:
Subscribe
DLA Production Lead Time:
Subscribe
Subscribe to View DLA Inventory and Forecast...

5977-00-928-6147 Management Data Management Data 5977-00-928-6147

Effective Date
Organization
Unit of Issue
Unit Price
Qty Unit Pack
Oct 2022
Department of the Army (DA)
EA
Subscribe
1
Oct 2021
Department of the Air Force (DF)
EA
Subscribe
1
Oct 2020
Department of the Air Force (DF)
EA
Subscribe
1
Oct 2019
Department of the Army (DA)
EA
Subscribe
1

Army Army

Materiel Category and Inventory Manager:
Q
Electronics Materiel (DLA/GSA Items)
Appropriation and Budget Activity:
2
Stock Fund Secondary Items
Management Inventory Segment:
2
Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
Weapons System / End Item / Homogeneous Group:
00
DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements:
X
Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force Air Force

Fund:
SF
Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
Budget:
9
57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
Aggregation Code:
EH
ELECTRONIC COMPONENTS
Price Validation Code:
N
The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ā€œLā€ or ā€œFā€, then it must be evaluated locally where purchased or fabricated.
Expendability
Recoverability
Repairability:
N
Expendable. Condemn at User. Stock Fund (except Munitions).

Navy Navy

Cognizance:
9B
Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps Marine Corps

Stores Account:
1
Stock Fund Account Item
Combat Essentiality:
5
Critical Repair Part to a Combat Essential End Item
Echelon Management:
B2
Material Identification:
T
Maintenance Float Secondary Non-depot Reparables
Operational Test:
No Special Procedures

5977-00-928-6147 Related Items NATO Stock Numbers Related to 5977-00-928-6147

5977-00-928-6147 Freight Data Freight Information 5977-00-928-6147

5977-00-928-6147 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062010. A Sub NMFC of Z. It has a NMFC Description of FITTINGS CONDUIT NOI. 5977-00-928-6147 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34496 which rates the freight between FCL and LCL. 5977-00-928-6147 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5977-00-928-6147 is not classified as a special type of cargo when transported by water. 5977-00-928-6147 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

5977-00-928-6147 Packaging Data Packaging Data 5977-00-928-6147

Responsible Activity
Packaging Data Source
Primary Inventory Control Activity (PICA)
--

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation
--
--
Electrical Instrument
Over 10lb
Less than 85G
No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying
1
--
--
--
--
Any Suitable Process
Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking
No Requirement
--
--
--
--
No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container
See Method of Preservation
--

5977-00-928-6147 Procurement History Procurement History 5977-00-928-6147 7 Records

Contract
Date
CAGE
Quantity
Net Price
Std Price
SPE7L119V0510
24 Oct 2018
Subscribe
326
Subscribe
Subscribe
SPE7L118V1507
13 Dec 2017
Subscribe
879
Subscribe
Subscribe
SPE7L117V0823P00001
14 Nov 2016
Subscribe
1870
Subscribe
Subscribe
SPE7L116V5430P00001
26 Sep 2016
Subscribe
342
Subscribe
Subscribe
SPE7L216V2488
29 Aug 2016
Subscribe
2000
Subscribe
Subscribe
SPE7L214V5358
29 Sep 2014
Subscribe
348
Subscribe
Subscribe
SPE7L514M1273
18 Mar 2014
Subscribe
382
Subscribe
Subscribe

5977-00-928-6147 Contracting Technical Data File (CTDF) Contracting Technical Data File (CTDF) 5977-00-928-6147 October 2021

Criticality and Quality

Critical Item Code:
X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):
F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:
