5970-00-198-6384
Bowl Insulator
5970001986384 001986384 SCD5290PT1 SCD5290ITEM1
An insulator used for wire entering or feedthru purposes. May include mounting and/or conducting hardware. Includes replacement bowls for feedthru insulators. Characterized by one or more bowl or bell shaped insulator surfaces. View more Bowl Insulator
May 2023
9
Marketplace 5970-00-198-6384
Request a Quotation from participating marketplace vendors
Related Documents 5970-00-198-6384 1+ Documents (More...)
/fsg-59/fsc-5970/us
5970-00-198-6384 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5970/us 5970-00-198-6384
RQST NE Updated Every Day 5970-00-198-6384 RQST Updated Every Day 5970-00-198-6384 RQST NE Related Documents
Restrictions 5970-00-198-6384
5970-00-198-6384 is a Bowl Insulator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5970-00-198-6384
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5970-00-198-6384
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5970-00-198-6384
- Part Number
- Manufacturer
- Status
- SCD5290PT1
- Manufacturer
- 80063 - Us Army Communications & Electronics (Active)
- Primary Buy
- Primary Buy
- SCD5290ITEM1
- 80063 - Us Army Communications & Electronics (Active)
- Primary Buy
- Primary Buy
Datasheet 5970-00-198-6384
- Characteristic
- Specifications
- FIIG
- Specifications
- A007A0
- Surface Treatment And Location [STLC]
- Overall Glazed
- Identification Code Color [AAPC]
- Brown
- Special Features [FEAT]
- Glazed Finish
- Furnished Items And Quantity [TMQY]
- Shackles 2,Pins 2,Lead Grommets 2,Cotter Pins 2
- Outside Diameter [ABKV]
- 4.500 Inches Nominal
- Top Diameter [AJQL]
- 2.500 Inches Nominal
- Height Above Mounting Surface [AYGJ]
- 1.875 Inches Nominal
- Top Hole Diameter [BQCT]
- 1.781 Inches Nominal
- First Counterbore Diameter [BXCZ]
- 2.125 Inches Nominal
- First Counterbore Depth [CFNT]
- 1.188 Inches Nominal
- Material And Location [MTLC]
- Overall Porcelain
- Material And Location [MTLC]
- Mounting Base Plastic
Similar Supply Items to 5970-00-198-6384
Freight Information 5970-00-198-6384
5970-00-198-6384 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 103660. A Sub NMFC of Z. It has a NMFC Description of ELECTRIC WIRE OR WIRING. 5970-00-198-6384 has not been rated for freight class when transported by Less-Than Truckload (LTL) freight. 5970-00-198-6384 is rated as class 55 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 53520 which rates the freight between FCL and LCL. 5970-00-198-6384 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5970-00-198-6384 is not classified as a special type of cargo when transported by water. 5970-00-198-6384 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
