5970-00-189-8059
Bowl Insulator
5970001898059 001898059 2C6397AJ3 7659-1E
An insulator used for wire entering or feedthru purposes. May include mounting and/or conducting hardware. Includes replacement bowls for feedthru insulators. Characterized by one or more bowl or bell shaped insulator surfaces. View more Bowl Insulator
January 2023
10
Marketplace 5970-00-189-8059
Request a Quotation from participating marketplace vendors
Related Documents 5970-00-189-8059 1+ Documents (More...)
/fsg-59/fsc-5970/us
United States (US) 4. 5970-00-189-8059 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 5970-00-189-8059 RQST Updated Every Day 5970-00-189-8059 RQST NE Related Documents
Restrictions 5970-00-189-8059
5970-00-189-8059 is a Bowl Insulator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5970-00-189-8059
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5970-00-189-8059
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5970-00-189-8059
- Part Number
- Manufacturer
- Status
- 2C6397AJ3
- Manufacturer
- 80063 - Us Army Communications & Electronics (Active)
- Primary Buy
- Primary Buy
- 7659-1E
- 00781 - Cessna Aircraft Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5970-00-189-8059
- Characteristic
- Specifications
- FIIG
- Specifications
- A007A0
- Height Above Mounting Surface [AYGJ]
- 0.375 Inches Nominal0.375 Inches Nominal
- Outside Diameter [ABKV]
- 0.750 Inches Nominal
- Material And Location [MTLC]
- Mounting Base Ceramic
- Material And Location [MTLC]
- Overall Ceramic
- Shoulder Depth [CRTT]
- 0.020 Inches Nominal0.020 Inches Nominal
- Shoulder Outside Diameter [AGPX]
- 0.620 Inches Nominal
- Special Features [FEAT]
- 0.070 In.By 0.020 In. Slot In One Wall
- Style Designator [STYL]
- Counterbore
Similar Supply Items to 5970-00-189-8059
Freight Information 5970-00-189-8059
5970-00-189-8059 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 103660. A Sub NMFC of Z. It has a NMFC Description of ELECTRIC WIRE OR WIRING. 5970-00-189-8059 has not been rated for freight class when transported by Less-Than Truckload (LTL) freight. 5970-00-189-8059 is rated as class 55 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 53520 which rates the freight between FCL and LCL. 5970-00-189-8059 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5970-00-189-8059 is not classified as a special type of cargo when transported by water. 5970-00-189-8059 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
