5970-00-068-3306
Special Purpose Electrical Insulation Sleeving
5970000683306 000683306 222A121-3-00-0 11608369-2 222A121-3-00
A rigid or flexible tubing having other than uniform fabricated shapes or forms. It is specifically designed to prevent any undesirable flow of current between conductors or between conductors and other objects. Includes shrinkable type items. Excludes items not having rated electrical characteristics. Also excludes BUSHING, SLEEVE; CABLE NIPPLE, ELECTRICAL; and INSULATION SLEEVING, ELECTRICAL. View more Special Purpose Electrical Insulation Sleeving
November 2023
14
Marketplace 5970-00-068-3306
Request a Quotation from participating marketplace vendors
Related Documents 5970-00-068-3306 5+ Documents (More...)
/fsg-59/fsc-5970/us
Photo 1/2 NSN 5970-00-068-3306 (Identification) 2/2 - - 1.
United States (US) 4. 5970-00-068-3306 Marketplace Restrictions Approved Sources Datasheet Management
5970000683306 000683306,222A121-3-00-0 www.nsnlookup.com /fsg-59/fsc-5970/us 5970-00-068-33065970000683306
000683306,222A121-3-00-0 222A121-3-00-011608369 Restrictions Approved Sources Datasheet Management https
Restrictions 5970-00-068-3306
5970-00-068-3306 is a Special Purpose Electrical Insulation Sleeving that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5970-00-068-3306
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5970-00-068-3306
- US Army (A918)
- Effective Date:
- 1 Dec 2004
- Supplementary Receivers:
- AZCL
- US Air Force (FXGG)
- Effective Date:
- 1 Aug 2004
- US Marine Corps (MC41)
- Effective Date:
- 1 Aug 2004
- US Navy (N9BG)
- Effective Date:
- 1 Aug 2004
- Supplementary Collaborators:
- GTHD
- Poland (WP)
- Poland (WP01)
- Effective Date:
- 1 Jun 2006
- Singapore (YJ)
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- United States of America (ZZ)
Approved Sources 5970-00-068-3306
- Part Number
- Manufacturer
- Status
- 222A121-3-00-0
- Manufacturer
- 06090 - Te Connectivity Corporation (Active)
- Primary Buy
- Primary Buy
- 222A121-3-00
- 06090 - Te Connectivity Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 11608369-2
- 19207 - U S Army Tank Automotive Command (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5970-00-068-3306
- Characteristic
- Specifications
- FIIG
- Specifications
- A22500
- Distance From Centerline Of Small End To Edge Of Large End [AFZS]
- 0.650 Inches Nominal After Unrestricted Recovery
- Distance From Intersecting Centerlines To Edge Of Small End [AFZR]
- 0.830 Inches Nominal As Supplied
- Distance From Intersecting Centerlines To Edge Of Small End [AFZR]
- 0.840 Inches Nominal After Unrestricted Recovery
- Distance From Top Of Shoulder To Small End Of Main Body [AGAM]
- 0.230 Inches Nominal After Unrestricted Recovery
- Angle Between Large End And Small End Centerlines In Deg [AGAP]
- 180.0 Nominal As Supplied
- Angle Between Large End And Small End Centerlines In Deg [AGAP]
- 90.0 Nominal After Unrestricted Recovery
- Color [HUES]
- Black
- Dielectric Material Voltage Rating Per Unit Thickness [UKBG]
- 200.0 Volts Per Mil /0.001 Inch/
- Environmental Protection [ADZC]
- Corrosion Resistant And Flame Resistant And Mildew Resistant And Water Resistant
- Flexibility [FLEX]
- Semirigid
- Height [HGTH]
- 0.880 Inches Minimum As Supplied
- Height [HGTH]
- 0.890 Inches Maximum After Unrestricted Recovery
- Material [MATT]
- Plastic, Polyolefin, Rt-301, Raychem Corp
- Large End Wall Thickness Of Main Body [AFZP]
- 0.050 Inches Maximum As Supplied
- Large End Wall Thickness Of Main Body [AFZP]
- 0.050 Inches Nominal After Unrestricted Recovery
- Main Body Small End Inside Diameter [AGAJ]
- 0.220 Inches Maximum After Unrestricted Recovery
- Main Body Small End Inside Diameter [AGAJ]
- 0.920 Inches Minimum As Supplied
- Main Body Large End Inside Diameter [AGAK]
- 0.410 Inches Maximum After Unrestricted Recovery
- Main Body Large End Inside Diameter [AGAK]
- 0.920 Inches Minimum As Supplied
- Reliability Indicator [AARG]
- Not Established
- Small End Wall Thickness Of Main Body [AFZQ]
- 0.050 Inches Maximum As Supplied
- Small End Wall Thickness Of Main Body [AFZQ]
- 0.050 Inches Nominal After Unrestricted Recovery
- Style Designator [STYL]
- Boot-90 Degrees
- Temp Rating [ABJH]
- -55.0 Deg Celsius
Weapon Systems (WSDC) 5970-00-068-3306
DLA Procurement Analysis 5970-00-068-3306
- Last Stock Position:
- 48 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5970-00-068-3306
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5970-00-068-3306
Freight Information 5970-00-068-3306
5970-00-068-3306 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 103300. A Sub NMFC of Z. It has a NMFC Description of INSULATING MATERIAL NOI. 5970-00-068-3306 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 53360 which rates the freight between FCL and LCL. 5970-00-068-3306 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5970-00-068-3306 is not classified as a special type of cargo when transported by water. 5970-00-068-3306 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Procurement History 5970-00-068-3306 2 Records
Contracting Technical Data File (CTDF) 5970-00-068-3306 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
