5970-00-037-4158
Electrical Insulation Tape
5970000374158 000374158 22-2
A narrow strip of woven or processed material less than twelve inches (304.8 mm) in width. It is specifically designed to prevent any undesirable flow of current between conductors and other objects. The item tends to resist any physical change, in contrast to an insulating compound in tape form which will fuse under a specified heat or pressure. It may or may not have adhesive backing. Excludes items not having definite rated electrical characteristics, such as TAPE, ADHESIVE, RUBBER; TAPE, PRESSURE SENSITIVE ADHESIVE; TAPE, SEMI-CONDUCTING, ELECTRICAL; and TAPE, SHIELDING, ELECTRICAL. See also INSULATION CLOTH, ELECTRICAL and INSULATING COMPOUND, ELECTRICAL. View more Electrical Insulation Tape
June 2023
8
Marketplace 5970-00-037-4158
Request a Quotation from participating marketplace vendors
Updated Every Day
Updated Every Day
Updated Every Day Updated Every Day Updated Every Day Related Documents 5970-00-037-4158 5+ Documents (More...)
5970-00-037-4158 RQST Updated Every Day 5970-00-037-4158 RQST NE Related Documents 5970-00-037-4158
Tape 5970000374158 RQST NE Updated Every Day 22-2 RQST NE Updated Every Day 5970-00-037-4158 RQST NE
Restrictions 5970-00-037-4158
5970-00-037-4158 is a Electrical Insulation Tape that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5970-00-037-4158
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5970-00-037-4158
- NASA (G900)
- Effective Date:
- 1 Apr 1991
Approved Sources 5970-00-037-4158
- Part Number
- Manufacturer
- Status
- 22-2
- Manufacturer
- 53387 - 3M Company (Replaced)
- Primary Buy
- Primary Buy
- 22-2
- 75037 - Minnesota Mining And Mfg Co 3M (Replaced)
- Original Design
- Original Design
- 22-2
- 76381 - 3M Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5970-00-037-4158
- Characteristic
- Specifications
- FIIG
- Specifications
- A14300
- Material [MATT]
- Plastic Overall
- Color [HUES]
- Black Overall
- Nominal Length [AKGG]
- 36.0 Yards
- Nominal Width [AKGF]
- 2.000 Inches
- Nominal Overall Thickness [CRZG]
- 0.0100 Inches
- Dielectric Withstanding Voltage In Volts [AAPB]
- 11000.0
- Features Provided [CBBL]
- Cement
Similar Supply Items to 5970-00-037-4158
Freight Information 5970-00-037-4158
5970-00-037-4158 has freight characteristics.. 5970-00-037-4158 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
