5962-01-254-8267
Digital Microcircuit
5962012548267 012548267 M38510/50306BRX ROM/PROM FAMILY 073 5812749P42
A microcircuit specifically designed to generate, modify, or process electrical signals which operate with two distinct or binary states. These states are commonly referred to as on and off, true and false, high and low, or "1" and "0". View more Digital Microcircuit
May 2023
3
Marketplace 5962-01-254-8267
Request a Quotation from participating marketplace vendors
Related Documents 5962-01-254-8267 5+ Documents (More...)
Photo 1/3 5962-01-254-8267 Photo 2/3 5962-01-254-8267 Photo 3/3 - - - 1.
M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation FedMall Updated Every 15 Minutes 5962-
M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation FedMall Updated Every 15 Minutes 5962-
M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation FedMall Updated Every 15 Minutes 5962-
M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation Subscribe to View Vendor Details...
, modify, or process M38510/50306BRX https//www.nsnlookup.com /fsg-59/fsc-5962/us 5962-01-254-8267 Digital
MICROCIRCUIT,DIGITAL 2 EA NS Request Quotation M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request
M38510/50306BRX MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation FedMall Updated Every 15 Minutes 5962-
Restrictions 5962-01-254-8267
5962-01-254-8267 is a Digital Microcircuit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item contains gold. This item is sensitive to Electrostatic Discharge.
Import and Export 5962-01-254-8267
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5962-01-254-8267
- National Security Agency (DGX1)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- DTX1
- Supplementary Receivers:
- TX
Approved Sources 5962-01-254-8267
- Part Number
- Manufacturer
- Status
- 5812749P42
- Manufacturer
- 94117 - Bae Systems Information And (Active)
- Primary Buy
- Primary Buy
- M38510/50306BRX
- 81349 - Military Specifications (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- ROM/PROM FAMILY 073
- 16236 - Dla Land And Maritime (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
Datasheet 5962-01-254-8267
- Characteristic
- Specifications
- FIIG
- Specifications
- A458A0
- Body Height [ADAU]
- 0.185 Inches Maximum
- Body Length [ADAQ]
- 1.060 Inches Maximum
- Body Width [ADAT]
- 0.220 Inches Minimum And 0.310 Inches Maximum
- Case Outline Source And Designator [CTFT]
- D-8 Mil-M-38510
- Design Function And Quantity [CSSL]
- 1 Gate, Array
- Features Provided [CBBL]
- Hermetically Sealed And Burn In And Bipolar And Monolithic And Programmable
- Maximum Power Dissipation Rating [AEHX]
- 2.0 Watts
- Operating Temp Range [AFGA]
- -55.0/+125.0 Deg Celsius
- Output Logic Form [CQWX]
- Transistor-Transistor Logic
- Inclosure Configuration [CQSZ]
- Dual-In-Line
- Inclosure Material [CQSJ]
- Ceramic
- Input Circuit Pattern [CQZP]
- 10 Input
- Precious Material And Location [PMLC]
- Terminal Surfaces Option Gold
- Precious Material [PRMT]
- Gold
- Time Rating Per Chacteristic [CZEQ]
- 45.00 Nanoseconds Maximum Propagation Delay Time, Low To High Level Output And 45.00 Nanoseconds Maximum Propagation Delay Time, High To Low Level Output
- Voltage Rating And Type Per Characteristic [CZEN]
- 0.5 Volts Minimum Power Source And 12.0 Volts Maximum Power Source
- Storage Temp Range [AFJQ]
- -65.0/+150.0 Deg Celsius
- Terminal Surface Treatment [CWSG]
- Solder
- Terminal Type And Quantity [TTQY]
- 20 Printed Circuit
- Test Data Document [TEST]
- 96906-Mil-Std-883 Standard (Includes Industry Or Association Standards, Individual Manufactureer Standards, Etc.).
DLA Procurement Analysis 5962-01-254-8267
Management Data 5962-01-254-8267
Similar Supply Items to 5962-01-254-8267
Freight Information 5962-01-254-8267
5962-01-254-8267 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5962-01-254-8267 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5962-01-254-8267 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 5962-01-254-8267 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5962-01-254-8267 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5962-01-254-8267 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5962-01-254-8267
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
