5962-01-247-9583
Memory Microcircuit
5962012479583 012479583 ROM/PROM FAMILY 030 722919-50 44310-1
A circuit designed to store information and/or coded instructions. Item has pins or other connections to install in a computer or computing device. Does not include magnetic drums, tapes, punched cards or the like. For items that have portable type connections see MEMORY, PORTABLE, SOLID STATE. View more Memory Microcircuit
May 2023
6
Marketplace 5962-01-247-9583
Request a Quotation from participating marketplace vendors
Related Documents 5962-01-247-9583 5+ Documents (More...)
FedMall Updated Every 15 Minutes 5962-01-247-9583 BUY NE FedMall Updated Every Day 5962-01-247-9583
RQST NE Updated Every Day 5962-01-247-9583 RQST Updated Every Day 5962-01-247-9583 RQST NE Related Documents
ROM/PROM FAMILY 030 44330-1 A circuit designed to store information and/or coded instructions.
ROM/PROM FAMILY 030 44316-1 A circuit designed to store information and/or coded instructions. https/
ROM/PROM FAMILY 030 44330-1 A circuit designed to store information and/or coded instructions.
ROM/PROM FAMILY 030 44346-1 A circuit designed to store information and/or coded instructions.
ROM/PROM FAMILY 030 44330-1 A circuit designed to store information and/or coded instructions.
ROM/PROM FAMILY 030 44316-1 A circuit designed to store information and/or coded instructions.
ROM/PROM FAMILY 030 44316-1 A circuit designed to store information and/or coded instructions.
www.nsnlookup.com /fsg-59/fsc-5962/us 5962-01-302-9154 Memory Microcircuit 5962013029154 013029154 722919-50
Restrictions 5962-01-247-9583
5962-01-247-9583 is a Memory Microcircuit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal. This item is sensitive to Electrostatic Discharge.
Import and Export 5962-01-247-9583
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5962-01-247-9583
- US Navy (N9BN)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
Approved Sources 5962-01-247-9583
- Part Number
- Manufacturer
- Status
- 44310-1
- Manufacturer
- 05869 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- ROM/PROM FAMILY 030
- 16236 - Dla Land And Maritime (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 722919-50
- 05869 - Raytheon Company (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
Datasheet 5962-01-247-9583
- Characteristic
- Specifications
- FIIG
- Specifications
- A458A0
- Body Height [ADAU]
- 0.145 Inches Minimum And 0.170 Inches Maximum
- Body Length [ADAQ]
- 0.880 Inches Minimum And 0.900 Inches Maximum
- Body Width [ADAT]
- 0.285 Inches Minimum And 0.300 Inches Maximum
- Features Provided [CBBL]
- Monolithic And Programmable And Schottky And High Speed And 3-State Output
- Memory Device Type [CZER]
- Rom
- Memory Capacity [CZZZ]
- Unknown
- Operating Temp Range [AFGA]
- -55.0/+125.0 Deg Celsius
- Output Logic Form [CQWX]
- Transistor-Transistor Logic
- Inclosure Configuration [CQSZ]
- Dual-In-Line
- Inclosure Material [CQSJ]
- Ceramic
- Input Circuit Pattern [CQZP]
- 12 Input
- Time Rating Per Chacteristic [CZEQ]
- 70.00 Nanoseconds Maximum Propagation Delay Time, Low To High Level Output And 70.00 Nanoseconds Maximum Propagation Delay Time, High To Low Level Output
- Voltage Rating And Type Per Characteristic [CZEN]
- 7.0 Volts Maximum Power Source
- Storage Temp Range [AFJQ]
- -65.0/+150.0 Deg Celsius
- Terminal Surface Treatment [CWSG]
- Solder
- Terminal Type And Quantity [TTQY]
- 18 Printed Circuit
- Test Data Document [TEST]
- 96906-Mil-Std-883 Standard (Includes Industry Or Association Standards, Individual Manufactureer Standards, Etc.).
Weapon Systems (WSDC) 5962-01-247-9583
DLA Procurement Analysis 5962-01-247-9583
Management Data 5962-01-247-9583
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5962-01-247-9583
Freight Information 5962-01-247-9583
5962-01-247-9583 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5962-01-247-9583 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5962-01-247-9583 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 5962-01-247-9583 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 738 for ocean manifesting and military sealift. 5962-01-247-9583 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5962-01-247-9583 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
