5962-00-884-0127
Digital Microcircuit
5962008840127 008840127 351-7090-040 SG123-03
A microcircuit specifically designed to generate, modify, or process electrical signals which operate with two distinct or binary states. These states are commonly referred to as on and off, true and false, high and low, or "1" and "0". View more Digital Microcircuit
May 2023
16
Marketplace 5962-00-884-0127
Request a Quotation from participating marketplace vendors
Related Documents 5962-00-884-0127 5+ Documents (More...)
United States (US) 4. 5962-00-884-0127 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 5962-00-884-0127 RQST Updated Every Day 5962-00-884-0127 RQST NE Related Documents
Restrictions 5962-00-884-0127
5962-00-884-0127 is a Digital Microcircuit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown. This item is sensitive to Electrostatic Discharge.
Import and Export 5962-00-884-0127
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5962-00-884-0127
- Spain (YB01)
- Effective Date:
- 1 Sep 2009
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5962-00-884-0127
- Part Number
- Manufacturer
- Status
- 351-7090-040
- Manufacturer
- 13499 - Rockwell Collins, Inc. (Active)
- Original Design
- Original Design
- SG123-03
- 93332 - Sylvania Electric Products Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5962-00-884-0127
- Characteristic
- Specifications
- FIIG
- Specifications
- A458A0
- Body Height [ADAU]
- 0.125 Inches Maximum
- Body Length [ADAQ]
- 0.685 Inches Minimum And 0.715 Inches Maximum
- Body Width [ADAT]
- 0.230 Inches Minimum And 0.265 Inches Maximum
- Design Function And Quantity [CSSL]
- 1 Gate, Nand
- Features Provided [CBBL]
- Expandable And Hermetically Sealed And Monolithic And Positive Outputs
- Maximum Power Dissipation Rating [AEHX]
- 30.0 Milliwatts
- Operating Temp Range [AFGA]
- +0.0/+75.0 Deg Celsius
- Output Logic Form [CQWX]
- Transistor-Transistor Logic
- Inclosure Configuration [CQSZ]
- Dual-In-Line
- Inclosure Material [CQSJ]
- Ceramic And Glass
- Input Circuit Pattern [CQZP]
- 8 Input
- Voltage Rating And Type Per Characteristic [CZEN]
- -1.5 Volts Minimum Power Source And 5.5 Volts Maximum Power Source
- Storage Temp Range [AFJQ]
- -65.0/+150.0 Deg Celsius
- Terminal Type And Quantity [TTQY]
- 14 Printed Circuit
- Terminal Surface Treatment [CWSG]
- Solder
- Test Data Document [TEST]
- 13499-351-7090 Drawing (This Is The Basic Governing Drawing, Such As A Contractor Drawing, Original Equipment Manufacturer Drawing, Etc.; Excludes Any Specification, Standard Or Other Document That May Be Referenced In A Basic Governing Drawing)
DLA Procurement Analysis 5962-00-884-0127
Management Data 5962-00-884-0127
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Nov 2007
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- N
- Disposal
- N
Similar Supply Items to 5962-00-884-0127
Freight Information 5962-00-884-0127
5962-00-884-0127 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5962-00-884-0127 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 5962-00-884-0127 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5962-00-884-0127 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5962-00-884-0127 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5962-00-884-0127
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- ESD sensitive electronic device requirements of MIL-STD-129 apply
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5962-00-884-0127 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
