5962-00-762-0598
Linear Microcircuit
5962007620598 007620598 GM820BM3A 541-075-001 403058 710DM
A microcircuit whose output is a function of the input; that is, the output varies in a predetermined and essentially predictable manner from the input signal. View more Linear Microcircuit
May 2023
30
Marketplace 5962-00-762-0598
Request a Quotation from participating marketplace vendors
Related Documents 5962-00-762-0598 5+ Documents (More...)
United States (US) 4. 5962-00-762-0598 Marketplace Restrictions Approved Sources Datasheet Management
,LINEAR RQST NS Request Quotation Updated Every Day 5962-00-762-0598 RQST NE Updated Every Day 5962-00
Linear Microcircuit 5962007620598 007620598 Account Upgrade 5962-00-762-0598Linear Microcircuit5962007620598
007620598 GM820BM3A 541-075-001 403058 710DM .. 541.075.001 MICROCIRCUIT,LINEAR 389 EA NS Request Quotation
/fsg-61/fsc-6130/us
GM820BM3A 541-075-001 403058 enable JavaScript in your web browser . 5962-99-118 https//www.nsnlookup.com
Linear Microcircuit 5962007620598 007620598 Account Upgrade 5962-00-762-0598Linear Microcircuit5962007620598
of items having a Power Supply Subassembly 6130010632170 Equipment Chassis5975661487569 661487569 403058
7569Electrical-Electronic Equipment Chassis5975661487569 661487569 https//www.nsnlookup.com /fsg-59/fsc-5962/us 5962-00-762-0598
Restrictions 5962-00-762-0598
5962-00-762-0598 is a Linear Microcircuit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown. This item is sensitive to Electrostatic Discharge.
Import and Export 5962-00-762-0598
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5962-00-762-0598
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Aug 2007
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5962-00-762-0598
- Part Number
- Manufacturer
- Status
- GM820BM3A
- Manufacturer
- 26512 - Northrop Grumman Systems Corporation (Active)
- Primary Buy
- Primary Buy
- 541-075-001
- C3141 - Elettronica Gmbh (Active)
- Secondary Buy
- Secondary Buy
- 710DM
- 07263 - Fairchild Semiconductor Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 403058
- 12909 - Cardion Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 403058
- 20284 - Aimtron Systems, Llc (Active)
- Vendor Drawing
- Vendor Drawing
- 541-075-001
- A1997 - Elettronica Spa (Active)
- NATO Reproduction
- NATO Reproduction
Datasheet 5962-00-762-0598
- Characteristic
- Specifications
- FIIG
- Specifications
- A458A0
- Body Height [ADAU]
- 0.160 Inches Minimum And 0.180 Inches Maximum
- Body Length [ADAQ]
- 0.735 Inches Minimum And 0.750 Inches Maximum
- Body Width [ADAT]
- 0.243 Inches Minimum And 0.261 Inches Maximum
- Case Outline Source And Designator [CTFT]
- To-116 Joint Electron Device Engineering Council
- Current Rating Per Characteristic [CTQX]
- 9.00 Milliamperes Maximum Supply
- Design Function And Quantity [CSSL]
- 1 Comparator, Differential
- Features Provided [CBBL]
- Hermetically Sealed And High Speed And Positive Outputs And W/Resistor
- Maximum Power Dissipation Rating [AEHX]
- 500.0 Milliwatts
- Operating Temp Range [AFGA]
- -55.0/+125.0 Deg Celsius
- Inclosure Configuration [CQSZ]
- Dual-In-Line
- Inclosure Material [CQSJ]
- Ceramic
- Input Circuit Pattern [CQZP]
- 2 Input
- Overall Height [ABKW]
- 0.350 Inches Maximum
- Voltage Rating And Type Per Characteristic [CZEN]
- 14.0 Volts Maximum Power Source
- Specification/Standard Data [ZZZK]
- 12909-403058 Manufacturers Specification Control
- Storage Temp Range [AFJQ]
- -65.0/+150.0 Deg Celsius
- Terminal Surface Treatment [CWSG]
- Solder
- Terminal Type And Quantity [TTQY]
- 14 Printed Circuit
Similar Supply Items to 5962-00-762-0598
Freight Information 5962-00-762-0598
5962-00-762-0598 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5962-00-762-0598 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 5962-00-762-0598 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5962-00-762-0598 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5962-00-762-0598 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5962-00-762-0598
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- ESD sensitive electronic device requirements of MIL-STD-129 apply
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
