5962-00-091-8931
Linear Microcircuit
5962000918931 000918931 934173-2C A-265 NCS1662-1
A microcircuit whose output is a function of the input; that is, the output varies in a predetermined and essentially predictable manner from the input signal. View more Linear Microcircuit
May 2023
7
Marketplace 5962-00-091-8931
Request a Quotation from participating marketplace vendors
Related Documents 5962-00-091-8931 5+ Documents (More...)
United States (US) 4. 5962-00-091-8931 Marketplace Restrictions Approved Sources Datasheet Management
Every Day 5962-00-091-8931 RQST NE Updated Every Day 5962-00-091-8931 RQST Updated Every Day 5962-00
MICROCIRCUIT https https//www.nsnlookup.com /fsg-59/fsc-5962/us 5962-00-091-8931 Linear Microcircuit
5962000918931 000918931 $1 a day Upgrade your Account Upgrade 5962-00-091-8931Linear Microcircuit5962000918931
958 01951LG80195 Managed by France NSN Created https//www.nsnlookup.com /fsg-59/fsc-5962/us 5962-00-091-8931
Linear Microcircuit 5962000918931 000918931 8931 MICROCIRCUIT,LINEAR 4 EA NS Request Quotation
Restrictions 5962-00-091-8931
5962-00-091-8931 is a Linear Microcircuit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown. This item is sensitive to Electrostatic Discharge.
End Users 5962-00-091-8931
- US Navy (N9BN)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTKE
Approved Sources 5962-00-091-8931
- Part Number
- Manufacturer
- Status
- 934173-2C
- Manufacturer
- 82577 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- A-265
- 64537 - Caes Systems Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- NCS1662-1
- 14936 - General Semiconductor Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- NCS1662-1
- 60991 - Microchip Technology Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5962-00-091-8931
- Characteristic
- Specifications
- FIIG
- Specifications
- A458A0
- Body Height [ADAU]
- 0.030 Inches Minimum And 0.070 Inches Maximum
- Body Length [ADAQ]
- 0.360 Inches Minimum And 0.410 Inches Maximum
- Body Width [ADAT]
- 0.240 Inches Minimum And 0.275 Inches Maximum
- Case Outline Source And Designator [CTFT]
- T0-87 Joint Electron Device Engineering Council
- Design Function And Quantity [CSSL]
- 1 Regulator, Voltage
- Features Provided [CBBL]
- Hermetically Sealed And Hybrid And Positive Outputs And Adjustable
- Maximum Power Dissipation Rating [AEHX]
- 500.0 Milliwatts
- Operating Temp Range [AFGA]
- -55.0/+125.0 Deg Celsius
- Inclosure Configuration [CQSZ]
- Flat Pack
- Inclosure Material [CQSJ]
- Ceramic And Glass
- Input Circuit Pattern [CQZP]
- 5 Input
- Voltage Rating And Type Per Characteristic [CZEN]
- 40.0 Volts Maximum Power Source
- Storage Temp Range [AFJQ]
- -65.0/+175.0 Deg Celsius
- Terminal Type And Quantity [TTQY]
- 14 Flat Leads
- Terminal Surface Treatment [CWSG]
- Solder
- Test Data Document [TEST]
- 82577-934173 Standard (Includes Industry Or Association Standards, Individual Manufactureer Standards, Etc.).
- Time Rating Per Chacteristic [CZEQ]
- 500.00 Nanoseconds Maximum Propagation Delay Time, Low To High Level Output And 500.00 Nanoseconds Maximum Propagation Delay Time, High To Low Level Output
Weapon Systems (WSDC) 5962-00-091-8931
DLA Procurement Analysis 5962-00-091-8931
Management Data 5962-00-091-8931
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5962-00-091-8931
Freight Information 5962-00-091-8931
5962-00-091-8931 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5962-00-091-8931 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 5962-00-091-8931 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5962-00-091-8931 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5962-00-091-8931 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
