5961-00-068-7667
Diode Semiconductor Device
5961000687667 000687667 RELEASE2911 1N1202RA 437D
A two electrode semiconductor device having an asymmetrical voltage - current characteristic. May or may not include mounting hardware and/or heatsink. Excludes LIGHT EMITTING DIODE and SEMICONDUCTOR DEVICE,PHOTO. For items containing material such as selenium and copper oxide, see RECIFIER, METALLIC. View more Diode Semiconductor Device
May 2023
33
Marketplace 5961-00-068-7667
Request a Quotation from participating marketplace vendors
Related Documents 5961-00-068-7667 5+ Documents (More...)
2 EA NS Request Quotation Updated Every Day 5961-00-068-7667 RQST NE Updated Every Day 5961-00-068-7667
RQST Updated Every Day 5961-00-068-7667 RQST NE Related Documents 5961-00-068-7667 5+ Documents ( More
JAN1N1202RA SEMICONDUCTOR DEVICE,DIODE RQST NS Request Quotation Subscribe to View Vendor Details... 1N1202RA
JAN1N1202RA SEMICONDUCTOR DEVICE,DIODE 13 EA NS Request Quotation Subscribe to View Vendor Details... 1N1202RA
Upgrade your Account Upgrade 5961-00-838-1151Diode Semiconductor Device5961008381151 008381151 RELEASE2911
Upgrade your Account Upgrade 5961-00-116-9363Diode Semiconductor Device5961001169363 001169363 RELEASE2911
CD-5847-1 413KBX-437D/124 A positive displacement device which utilzes the rotating motion of one or
/fsg-43/fsc-4320/us 4320-01-415-8304 Rotary Pump 4320014158304014158304 413KBX-437DCD-5847-1413KBX-437D
Upgrade your Account Upgrade 5961-00-990-4695Diode Semiconductor Device5961009904695 009904695 RELEASE2911
Diode Semiconductor Device 5961000687667 Upgrade your Account Upgrade 5961-00-068-7667Diode Semiconductor
Restrictions 5961-00-068-7667
5961-00-068-7667 is a Diode Semiconductor Device that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5961-00-068-7667
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5961-00-068-7667
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 5961-00-068-7667
- Part Number
- Manufacturer
- Status
- 1N1202RA
- Manufacturer
- 80131 - Electronic Industries Association (Active)
- Primary Buy
- Primary Buy
- RELEASE2911
- 80131 - Electronic Industries Association (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 1N1202RA
- 09214 - General Electric Co Semi-Conductor (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 437D
- 05277 - Westinghouse Electric Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5961-00-068-7667
- Characteristic
- Specifications
- FIIG
- Specifications
- A110A0
- Current Rating Per Characteristic [CTQX]
- 240.00 Amperes Maximum Average Forward Current Averaged Over A Full 60-Hz Cycle
- Features Provided [CBBL]
- Hermetically Sealed Case
- Maximum Operating Temp Per Measurement Point [CTSG]
- 150.0 Deg Celsius Ambient Air
- Mounting Facility Quantity [AKPV]
- 1
- Mounting Method [AXGY]
- Threaded Stud
- Nominal Thread Size [CQJX]
- 0.190 Inches
- Overall Diameter [ADAV]
- 0.424 Inches Maximum
- Inclosure Material [ABBH]
- Metal
- Joint Electronic Device Engineering Council/Jedec/Case Outline Designation [ALAZ]
- Do-4
- Semiconductor Material [CTMZ]
- Silicon
- Overall Length [ABHP]
- 0.405 Inches Maximum
- Overall Width Across Flats [CCDG]
- 0.424 Inches Minimum And 0.437 Inches Maximum
- Voltage Rating In Volts Per Characteristic [CTQN]
- 200.0 Maximum Reverse Voltage, Peak
- Specification/Standard Data [ZZZK]
- 80131-Release2911 Professional/Industrial Association Specification
- Terminal Type And Quantity [TTQY]
- 1 Tab, Solder Lug And 1 Threaded Stud
- Thread Series Designator [THSD]
- Unf
Similar Supply Items to 5961-00-068-7667
Freight Information 5961-00-068-7667
5961-00-068-7667 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063025. A Sub NMFC of Z. It has a NMFC Description of SEMICONDUCTORS/DEVICES NOI ETC. 5961-00-068-7667 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34525 which rates the freight between FCL and LCL. 5961-00-068-7667 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5961-00-068-7667 is not classified as a special type of cargo when transported by water. 5961-00-068-7667 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
