5960-00-284-9751
Electron Tube Retainer
5960002849751 002849751 308-1006P1 S88-5122ISSUE10 S308-1006P1 49562
An item specifically designed to restrain the movement of an electron tube when the latter is mounted in another item, normally a tube socket. Includes clamps, clips, and similar restraining devices specifically designed for this function. View more Electron Tube Retainer
May 2023
17
Marketplace 5960-00-284-9751
Request a Quotation from participating marketplace vendors
Related Documents 5960-00-284-9751 5+ Documents (More...)
Every Day 5960-00-284-9751 RQST Updated Every Day 5960-00-284-9751 RQST NE Related Documents 5960-00-
Documents 5960-00- Electron Tube Retainer 5960002849751 RQST NE Updated Every Day ... 49562 BRUSH ATTACHMENT
BRUSH ATTACHMENT,VACUUM 2 EA NS Request Quotation Updated Every Day 49562 RQST NE Updated Every Day
49562 BRUSH ATTACHMENT,VACUUM 2 EA NS Request Quotation Updated Every Day 49562 RQST NE Updated Every
Details... 495621 MICROCIRCUIT,DIGITAL 1 EA NS Request Quotation Subscribe to View Vendor Details... 49562
AMPAL16L8ADMB MICROCIRCUIT,DIGITAL 52 EA NS Request https//www.nsnlookup.com /fsg-59/fsc-5960/us 5960-00-284-9751
Restrictions 5960-00-284-9751
5960-00-284-9751 is a Electron Tube Retainer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5960-00-284-9751
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5960-00-284-9751
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
Approved Sources 5960-00-284-9751
- Part Number
- Manufacturer
- Status
- 308-1006P1
- Manufacturer
- 94144 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- S88-5122ISSUE10
- 94144 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- 308-1006P1
- 3B150 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- S308-1006P1
- 3B150 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- S88-5122ISSUE10
- 3B150 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- 308-1006P1
- 49956 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- S308-1006P1
- 49956 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- S88-5122ISSUE10
- 49956 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 49562
- 79213 - Waterfield J B Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5960-00-284-9751
- Characteristic
- Specifications
- FIIG
- Specifications
- A062A0
- Distance From Retainer Center To Centerline Of Mounting Facility [AGTB]
- 0.875 Inches Nominal
- Distance From Retainer Center To End Of Extended Clip [AGTC]
- 1.438 Inches Nominal
- Electron Tube Base Accommodated Diameter [AGTR]
- +1.337/+1.377 Inches
- Accommodated Item Securing Device Type [AGTM]
- Clamp
- Angle Between Mounting Facility And Loop Hinge Centerlines In Deg [AGTE]
- 180.0
- Features Provided [CBBL]
- Post Locking Tab
- Mounting Facility Type And Quantity [AXHR]
- 1 Slot Single Mounting Facility
- Mounting Slot Length [ABVG]
- 0.312 Inches Nominal Single Mounting Facility
- Mounting Slot Width [ABTD]
- 0.188 Inches Nominal Single Mounting Facility
- Material [MATT]
- Steel
- Inside Diameter [AARX]
- 1.337 Inches Minimum And 1.377 Inches Maximum
- Overall Height [ABKW]
- 0.625 Inches Nominal
- Style Designator [STYL]
- Single Foot, Clip Locked, Tension Clamp
- Surface Treatment [SFTT]
- Any Acceptable
Similar Supply Items to 5960-00-284-9751
Freight Information 5960-00-284-9751
5960-00-284-9751 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061680. A Sub NMFC of Z. It has a NMFC Description of ELEC WIRING PLUGS ETC. 5960-00-284-9751 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5960-00-284-9751 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34570 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5960-00-284-9751 is not classified as a special type of cargo when transported by water. 5960-00-284-9751 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
