5955-01-407-8591
Crystal Controlled Oscillator
5955014078591 014078591 MIL-PRF-55310/14 M55310/14-B05A2. M55310/14-B05A2M457600 MIL-O-55310/14
An oscillator whose operating frequency(ies) is controlled by a CRYSTAL UNIT, QUARTZ. For an oscillator controlled by a device other than a crystal, see OSCILLATOR (1), NONCRYSTAL CONTROLLED. See also GENERATOR, SIGNAL; and CALIBRATOR, FREQUENCY. Excludes FREQUENCY SUPPLY, TELEPHONE CARRIER; RESONATOR, TUNING FORK; and OSCILLATOR, PULSE DELAY. View more Crystal Controlled Oscillator
May 2023
4
Marketplace 5955-01-407-8591
Request a Quotation from participating marketplace vendors
Related Documents 5955-01-407-8591 5+ Documents (More...)
M55310/14-B05A2M457600 MIL-O-55310/14 An oscillator whose operating frequency(ies) is controlled by a
) https//www.nsnlookup.com /fsg-59/fsc-5955/us 5955-01-407-8591 Crystal Controlled Oscillator 5955014078591
01-210-7190 Crystal Controlled Oscillator 5955012107190 1D402B11500000 M55310/14-B08A11M50000 MIL-O-55310/14
-178-8270 Crystal Controlled Oscillator 5955011788270 M55310/14-B05020 M55310/14-B05A20M00000 MIL-O-55310/14
controlled An oscillator whose An oscillator whose operating frequency M55310/14-B09A17M00000 MIL-O-55310/14
Crystal Controlled Oscillator 5955014078591 M55310/14-B05A2M457600 MIL-O-55310/14 An oscillator
01-210-7190 Crystal Controlled Oscillator 5955012107190 1D402B11500000 M55310/14-B08A11M50000 MIL-O-55310/14
https//www.nsnlookup.com /fsg-59/fsc-5955/us 5955-01-407-8591 Crystal Controlled Oscillator 5955014078591
Restrictions 5955-01-407-8591
5955-01-407-8591 is a Crystal Controlled Oscillator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5955-01-407-8591
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-01-407-8591
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- KE
Approved Sources 5955-01-407-8591
- Part Number
- Manufacturer
- Status
- M55310/14-B05A2M457600
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-55310/14
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-O-55310/14
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- M55310/14-B05A2.
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5955-01-407-8591
- Characteristic
- Specifications
- FIIG
- Specifications
- A32200
- Average Life Measurement [AFSU]
- Not Rated
- Basic Shape Style [AGTA]
- Rectangular Or Square
- Connection Type And Location [BJBP]
- Pin Bottom
- Connection Contact Type And Quantity [BJBW]
- 14 Pin External
- Control Type [AQZF]
- Remote
- External Dc Operating Voltage In Volts [BKFB]
- 4.5 Minimum Single Voltage And 5.5 Maximum Single Voltage
- Frequency Per Channel [BHTB]
- 2.4576 Megahertz Nominal Operating Channel
- Circuit Construction Type [BHSX]
- Solid State
- Operating Control Method [ALBM]
- Automatic
- Operating Temp Range [AFGA]
- -55.0/+125.0 Deg Celsius
- Inclosure Type [AKNA]
- Hermetically Sealed
- Installation Design [AMQY]
- Module
- Overall Height [ABKW]
- 0.200 Inches Maximum
- Overall Length [ABHP]
- 0.887 Inches Maximum
- Overall Width [ABMK]
- 0.540 Inches Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-O-55310/14 Government Specification
- Test Data Document [TEST]
- 81349-Mil-O-55310 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Weapon Systems (WSDC) 5955-01-407-8591
DLA Procurement Analysis 5955-01-407-8591
Management Data 5955-01-407-8591
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5955-01-407-8591
Freight Information 5955-01-407-8591
5955-01-407-8591 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 060500. A Sub NMFC of X. It has a NMFC Description of ELECTRICAL EQUIPMENT GROUP. 5955-01-407-8591 has not been rated for freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 81820 which rates the freight between FCL and LCL. 5955-01-407-8591 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5955-01-407-8591 is not classified as a special type of cargo when transported by water. 5955-01-407-8591 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5955-01-407-8591
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 0.9" H x 0.5" W x 0.2" L
- --
- --
- --
- Any Suitable Process
- 0.9" H x 0.5" W x 0.2" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- ESD sensitive electronic device requirements of MIL-STD-129 apply
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
