5955-01-261-8939
Quartz Crystal Unit
5955012618939 012618939 MIL-PRF-3098/76 CR1/U7M122220 CR1DU7-122220MHZ MILC3098
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
May 2023
10
Marketplace 5955-01-261-8939
Request a Quotation from participating marketplace vendors
Related Documents 5955-01-261-8939 5+ Documents (More...)
Photo 1/2 NSN 5955-01-261-8939 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5955-01-261-8939 RQST Updated Every Day 5955-01-261-8939 RQST NE Related Documents
Restrictions 5955-01-261-8939
5955-01-261-8939 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5955-01-261-8939
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-01-261-8939
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Brazil (YA01)
- Effective Date:
- 1 Jul 2001
Approved Sources 5955-01-261-8939
- Part Number
- Manufacturer
- Status
- CR1/U7M122220
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-3098/76
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- CR1DU7-122220MHZ
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MILC3098
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5955-01-261-8939
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Drive Level Rating [CQYL]
- 27.0 Milliwatts Minimum And 33.0 Milliwatts Maximum
- Body Length [ADAQ]
- 1.282 Inches Maximum
- Body Thickness [ADPR]
- 0.411 Inches Maximum
- Body Width [ADAT]
- 1.125 Inches Maximum
- Center To Center Distance Between Terminals [CQBK]
- 0.490 Nominal Mils And 0.510 Nominal Centimeters
- Circuit Resonance [AEHD]
- Antiresonance
- Equivalent Resistance Value In Ohms [CRMP]
- 50.0 Maximum
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.005/+0.005
- Holder Cover Material [AEHS]
- Metal
- Operating Temp Range [AFGA]
- -55.0/+90.0 Deg Celsius
- Mode Of Oscillation [AEHC]
- Fundamental
- Load Capacitance In Picofarads [AEHE]
- 34.5 Minimum And 35.5 Maximum
- Overall Length [ABHP]
- 1.937 Inches Maximum
- Overall Thickness [ADUM]
- 0.460 Inches Maximum
- Overall Width [ABMK]
- 1.170 Inches Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-C-3098/76 Government Specification
- Specified Frequency [AEHG]
- 7.12222 Megahertz
- Style Designator [STYL]
- Oval Body, Pin Terminals
- Terminal Length [ABJT]
- 0.625 Inches Minimum And 0.655 Inches Maximum
- Terminal Diameter [AEBT]
- 0.123 Inches Minimum And 0.127 Inches Maximum
- Test Data Document [TEST]
- 81349-Milc3098 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
DLA Procurement Analysis 5955-01-261-8939
Management Data 5955-01-261-8939
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5955-01-261-8939
Freight Information 5955-01-261-8939
5955-01-261-8939 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063025. A Sub NMFC of Z. It has a NMFC Description of SEMICONDUCTORS/DEVICES NOI ETC. 5955-01-261-8939 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34525 which rates the freight between FCL and LCL. 5955-01-261-8939 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5955-01-261-8939 is not classified as a special type of cargo when transported by water. 5955-01-261-8939 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
