5955-01-010-5458
Quartz Crystal Unit
5955010105458 010105458 289-7074-020 289-7074-020M20 289-7074-020H-3W ER289-7074-020
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
May 2023
18
Marketplace 5955-01-010-5458
Request a Quotation from participating marketplace vendors
Related Documents 5955-01-010-5458 3+ Documents (More...)
Photo 1/2 NSN 5955-01-010-5458 (Identification) 2/2 - - 1.
United States (US) 4. 5955-01-010-5458 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 5955-01-010-5458
5955-01-010-5458 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5955-01-010-5458
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-01-010-5458
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- KE
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 May 2015
Approved Sources 5955-01-010-5458
- Part Number
- Manufacturer
- Status
- 289-7074-020
- Manufacturer
- 13499 - Rockwell Collins, Inc. (Active)
- Primary Buy
- Primary Buy
- 289-7074-020M20
- 00136 - Microsemi Corp. - High Performance (Active)
- Secondary Buy
- Secondary Buy
- 289-7074-020H-3W
- 75378 - Cts Inc (Active)
- Secondary Buy
- Secondary Buy
- ER289-7074-020
- 13571 - Electronic Research Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5955-01-010-5458
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Drive Level Rating [CQYL]
- 6.0 Milliwatts Maximum
- Body Thickness [ADPR]
- 0.150 Inches Maximum
- Body Width [ADAT]
- 0.402 Inches Maximum
- Center To Center Distance Between Terminals [CQBK]
- 0.183 Nominal Mils And 0.200 Nominal Centimeters
- Circuit Resonance [AEHD]
- Antiresonance
- Equivalent Resistance Value In Ohms [CRMP]
- 25.0 Maximum
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.005/+0.005
- Holder Cover Material [AEHS]
- Metal
- Operating Temp Range [AFGA]
- -55.0/+85.0 Deg Celsius
- Mode Of Oscillation [AEHC]
- Fundamental
- Load Capacitance In Picofarads [AEHE]
- 29.5 Minimum And 30.5 Maximum
- Shunt Capacitance In Picofarads [AEHF]
- 7.0 Maximum
- Overall Length [ABHP]
- 0.530 Inches Maximum
- Overall Thickness [ADUM]
- 0.183 Inches Maximum
- Overall Width [ABMK]
- 0.435 Inches Maximum
- Specified Frequency [AEHG]
- 11.0592 Megahertz
- Style Designator [STYL]
- Oval Body, Wire Leads
- Terminal Diameter [AEBT]
- 0.015 Inches Minimum And 0.019 Inches Maximum
- Terminal Length [ABJT]
- 1.500 Inches Minimum
Weapon Systems (WSDC) 5955-01-010-5458
DLA Procurement Analysis 5955-01-010-5458
Management Data 5955-01-010-5458
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5955-01-010-5458
Freight Information 5955-01-010-5458
5955-01-010-5458 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063025. A Sub NMFC of Z. It has a NMFC Description of SEMICONDUCTORS/DEVICES NOI ETC. 5955-01-010-5458 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34525 which rates the freight between FCL and LCL. 5955-01-010-5458 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5955-01-010-5458 is not classified as a special type of cargo when transported by water. 5955-01-010-5458 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5955-01-010-5458
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5955-01-010-5458 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
