5955-00-781-0270
Quartz Crystal Unit
5955007810270 007810270 MIL-C-3098/31 CR53A/U71M61100 CR-53A/U71.611000MHZ
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
May 2023
22
Marketplace 5955-00-781-0270
Request a Quotation from participating marketplace vendors
Related Documents 5955-00-781-0270 5+ Documents (More...)
Photo 1/4 5955-00-781-0270 Photo 2/4 5955-00-781-0270 Photo 3/4 NSN 5955-00-781-0270 (Identification
NE Updated Every Day 5955-00-781-0270 RQST Updated Every Day 5955-00-781-0270 RQST NE Related Documents
Restrictions 5955-00-781-0270
5955-00-781-0270 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5955-00-781-0270
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-00-781-0270
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5955-00-781-0270
- Part Number
- Manufacturer
- Status
- CR53A/U71M61100
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-C-3098/31
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- CR-53A/U71.611000MHZ
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5955-00-781-0270
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Drive Level Rating [CQYL]
- 20.0 Milliwatts Nominal And 16.0 Milliwatts Minimum And 24.0 Milliwatts Maximum
- Body Length [ADAQ]
- 0.775 Inches Maximum
- Body Thickness [ADPR]
- 0.317 Inches Maximum
- Body Width [ADAT]
- 0.725 Inches Maximum
- Center To Center Distance Between Terminals [CQBK]
- 0.486 Nominal Inches
- Circuit Resonance [AEHD]
- Series Resonance
- Equivalent Resistance Value In Ohms [CRMP]
- 60.0 Nominal
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.005/+0.005
- Holder Cover Material [AEHS]
- Metal
- Operating Temp Range [AFGA]
- -55.0/+105.0 Deg Celsius
- Mode Of Oscillation [AEHC]
- Fifth Overtone
- Shunt Capacitance In Picofarads [AEHF]
- 7.0 Maximum
- Overall Length [ABHP]
- 1.023 Inches Maximum
- Overall Thickness [ADUM]
- 0.352 Inches Maximum
- Overall Width [ABMK]
- 0.757 Inches Maximum
- Specified Frequency [AEHG]
- 71.611 Megahertz
- Style Designator [STYL]
- Oval Body, Pin Terminals
- Terminal Diameter [AEBT]
- 0.050 Inches Nominal
- Terminal Length [ABJT]
- 0.238 Inches Nominal
- Test Data Document [TEST]
- 81349-Milc3098 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Similar Supply Items to 5955-00-781-0270
Freight Information 5955-00-781-0270
5955-00-781-0270 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5955-00-781-0270 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5955-00-781-0270 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5955-00-781-0270 is not classified as a special type of cargo when transported by water. 5955-00-781-0270 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
