5955-00-267-1151
Quartz Crystal Unit
5955002671151 002671151 CR18U 291-8146-00
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
May 2023
9
Marketplace 5955-00-267-1151
Request a Quotation from participating marketplace vendors
Related Documents 5955-00-267-1151 5+ Documents (More...)
Photo 1/2 NSN 5955-00-267-1151 (Identification) 2/2 - - 1.
Every Day 5955-00-267-1151 RQST Updated Every Day 5955-00-267-1151 RQST NE Related Documents 5955-00
CR18U https//www.nsnlookup.com /fsg-59/fsc-5955/uk 5955-99-141-0515 Crystal 5955991410515991410515,CR18U
Crystal 5955991410515991410515,CR18U Crystal 5955991410515991410515,CR18U ... ) https//www.nsnlookup.com
/www.nsnlookup.com /fsg-59/fsc-5955/us 5955-00-267-6733 Quartz Crystal Unit 5955002676733002676733 CR18U
Crystal 5955991410515991410515,CR18U ... ) https//www.nsnlookup.com https//www.nsnlookup.com /fsg-59
Restrictions 5955-00-267-1151
5955-00-267-1151 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5955-00-267-1151
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-00-267-1151
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5955-00-267-1151
- Part Number
- Manufacturer
- Status
- 291-8146-00
- Manufacturer
- 13499 - Rockwell Collins, Inc. (Active)
- Primary Buy
- Primary Buy
- CR18U
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 5955-00-267-1151
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Body Length [ADAQ]
- 0.755 Inches Minimum And 0.775 Inches Maximum
- Center To Center Distance Between Terminals [CQBK]
- 0.478 Nominal Mils And 0.494 Nominal Centimeters
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.005/+0.005
- Operating Temp Range [AFGA]
- -55.0/+90.0 Deg Celsius
- Mode Of Oscillation [AEHC]
- Fundamental
- Overall Length [ABHP]
- 0.998 Inches Minimum And 1.003 Inches Maximum
- Overall Thickness [ADUM]
- 0.338 Inches Minimum And 0.343 Inches Maximum
- Overall Width [ABMK]
- 0.745 Inches Minimum And 0.750 Inches Maximum
- Specified Frequency [AEHG]
- 5.800 Megahertz
- Style Designator [STYL]
- Oval Body, Pin Terminals
- Terminal Diameter [AEBT]
- 0.048 Inches Minimum And 0.052 Inches Maximum
- Terminal Length [ABJT]
- 0.223 Inches Minimum And 0.248 Inches Maximum
Similar Supply Items to 5955-00-267-1151
Freight Information 5955-00-267-1151
5955-00-267-1151 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5955-00-267-1151 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5955-00-267-1151 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5955-00-267-1151 is not classified as a special type of cargo when transported by water. 5955-00-267-1151 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
