5955-00-267-1147
Quartz Crystal Unit
5955002671147 002671147 MILC3098-3 CR-18/U8.150000MHZ
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
May 2023
May 2023
NATO Update Count
11
11
NATO Data Quality
Marketplace 5955-00-267-1147
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5955-00-267-1147 3+ Documents (More...)
MILC3098-3 CR-18/U8.150000MHZ An item which consists of a quartz crystal resonator(s), suitably mounted
MILC3098-3 CRYSTAL UNIT,QUARTZ 1 EA NS Request Quotation Updated Every Day 5955-00-267-1147 RQST NE Updated
Every Day 5955-00-267-1147 RQST Updated Every Day 5955-00-267-1147 RQST NE Related Documents 5955-00
MILC3098-3 CRYSTAL UNIT,QUARTZ 1 EA NS Request Quotation Updated Every Day 5955-00-267-1147 RQST NE Updated
Every Day 5955-00-267-1147 RQST Updated Every Day 5955-00-267-1147 RQST NE Related Documents 5955-00
850-9943 5955-01-228-3349 5955-00-781-0270 5955-00-762-6608 5955-00-132-9429 5955-01-261-8939 5955-00-267-1147
850-9943 5955-01-228-3349 5955-00-781-0270 5955-00-762-6608 5955-00-132-9429 5955-01-261-8939 5955-00-267-1147
Restrictions 5955-00-267-1147
5955-00-267-1147 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5955-00-267-1147
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-00-267-1147
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5955-00-267-1147
- Part Number
- Manufacturer
- Status
- CR-18/U8.150000MHZ
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MILC3098-3
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 5955-00-267-1147
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Body Length [ADAQ]
- 0.755 Inches Minimum And 0.775 Inches Maximum
- Center To Center Distance Between Terminals [CQBK]
- 0.478 Nominal Mils And 0.494 Nominal Centimeters
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.005/+0.005
- Operating Temp Range [AFGA]
- -55.0/+90.0 Deg Celsius
- Mode Of Oscillation [AEHC]
- Fundamental
- Overall Length [ABHP]
- 0.978 Inches Minimum And 1.023 Inches Maximum
- Overall Thickness [ADUM]
- 0.338 Inches Minimum And 0.343 Inches Maximum
- Overall Width [ABMK]
- 0.745 Inches Minimum And 0.750 Inches Maximum
- Specified Frequency [AEHG]
- 8.150 Kilohertz
- Style Designator [STYL]
- Oval Body, Pin Terminals
- Terminal Diameter [AEBT]
- 0.048 Inches Minimum And 0.052 Inches Maximum
- Terminal Length [ABJT]
- 0.223 Inches Minimum And 0.248 Inches Maximum
Similar Supply Items to 5955-00-267-1147
Freight Information 5955-00-267-1147
5955-00-267-1147 has freight characteristics.. 5955-00-267-1147 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
Packaging Data 5955-00-267-1147
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- --
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
