5955-00-132-9429
Quartz Crystal Unit
5955001329429 001329429 MILC16TYPECR1AAR8107-140KC MILC16TYPECR1AAR8107-140
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
May 2023
15
Marketplace 5955-00-132-9429
Request a Quotation from participating marketplace vendors
Related Documents 5955-00-132-9429 3+ Documents (More...)
Photo 1/2 NSN 5955-00-132-9429 (Identification) 2/2 - - 1.
MILC16TYPECR1AAR8107-140 CRYSTAL UNIT,QUARTZ 123 EA NS Request Quotation Updated Every Day 5955-00-132
Restrictions 5955-00-132-9429
5955-00-132-9429 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5955-00-132-9429
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-00-132-9429
- Germany (ZG01)
- Effective Date:
- 1 Nov 2011
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5955-00-132-9429
- Part Number
- Manufacturer
- Status
- MILC16TYPECR1AAR8107-140KC
- Manufacturer
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MILC16TYPECR1AAR8107-140
- D1863 - Kvg Quartz Crystal Technology Gmbh (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5955-00-132-9429
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Body Length [ADAQ]
- 1.155 Inches Minimum And 1.285 Inches Maximum
- Center To Center Distance Between Terminals [CQBK]
- 0.495 Nominal Mils And 0.505 Nominal Centimeters
- Circuit Resonance [AEHD]
- Antiresonance
- Equivalent Resistance Value In Ohms [CRMP]
- 40.0 Nominal
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.020/+0.020
- Holder Cover Material [AEHS]
- Plastic
- Operating Temp Range [AFGA]
- -55.0/+90.0 Deg Celsius
- Mode Of Oscillation [AEHC]
- Fundamental
- Load Capacitance In Picofarads [AEHE]
- 34.5 Minimum And 35.5 Maximum
- Overall Length [ABHP]
- 1.750 Inches Minimum And 1.940 Inches Maximum
- Overall Thickness [ADUM]
- 0.380 Inches Minimum And 0.460 Inches Maximum
- Overall Width [ABMK]
- 1.090 Inches Minimum And 1.170 Inches Maximum
- Specified Frequency [AEHG]
- 8.10714 Megahertz
- Style Designator [STYL]
- Rectangular Body, Pin Terminals
- Terminal Diameter [AEBT]
- 0.120 Inches Minimum And 0.130 Inches Maximum
- Terminal Length [ABJT]
- 0.595 Inches Minimum And 0.655 Inches Maximum
- Test Data Document [TEST]
- 81349-Milc3098 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
DLA Procurement Analysis 5955-00-132-9429
Management Data 5955-00-132-9429
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Dec 1978
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- Z
- Discontinued-Use 5955-00-181-0520
- Z
Similar Supply Items to 5955-00-132-9429
Freight Information 5955-00-132-9429
5955-00-132-9429 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063025. A Sub NMFC of Z. It has a NMFC Description of SEMICONDUCTORS/DEVICES NOI ETC. 5955-00-132-9429 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34525 which rates the freight between FCL and LCL. 5955-00-132-9429 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5955-00-132-9429 is not classified as a special type of cargo when transported by water. 5955-00-132-9429 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5955-00-132-9429 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
