5955-00-105-2058
Quartz Crystal Unit
5955001052058 001052058 MIL-PRF-3098/33 CR55/U17M98500 MIL-C-3098/33
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
Managed by United States
NSN Created on 3 Jul 1968
Data Last Changed
May 2023
May 2023
NATO Update Count
7
7
NATO Data Quality
Marketplace 5955-00-105-2058
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5955-00-105-2058 5+ Documents (More...)
MIL-PRF-3098/33 CR55/U17M98500 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s)
Photo 1/3 5955-00-105-2058 Photo 2/3 NSN 5955-00-105-2058 (Identification) 3/3 - - - 1.
BUY NE FedMall Updated Every Day 5955-00-105-2058 RQST NE Updated Every Day 5955-00-105-2058 RQST
Photo 1/3 5955-00-105-2058 Photo 2/3 NSN 5955-00-105-2058 (Identification) 3/3 - - - 1.
BUY NE FedMall Updated Every Day 5955-00-105-2058 RQST NE Updated Every Day 5955-00-105-2058 RQST
CR55/U18M18500 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s), suitably
CR55/U26M24999 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s), suitably
fsg-59/fsc-5955/us 5955-00-105-2058 Quartz Crystal Unit 5955001052058 001052058 CR55/U17M98500 MIL-C
CR55/U26M24999 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s), suitably
fsg-59/fsc-5955/us 5955-00-105-2058 Quartz Crystal Unit 5955001052058 001052058 CR55/U17M98500 MIL-C
289-7209-010 CR55/U29M50000 MIL-C-3098/33 An item which consists of a quartz crystal resonator
CR55/U32M80370 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s), suitably
//www.nsnlookup.com /fsg-59/fsc-5955/us 5955-00-105-2058 Quartz Crystal Unit 5955001052058 001052058
CR55/U32M80370 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s), suitably
//www.nsnlookup.com /fsg-59/fsc-5955/us 5955-00-105-2058 Quartz Crystal Unit 5955001052058 001052058
a day Upgrade your Account Upgrade 5955-00-842-4698Quartz Crystal Unit5955008424698 008424698 MIL-PRF-3098/33
CR55/U26M24999 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s), suitably
fsg-59/fsc-5955/us 5955-00-105-2067 Quartz Crystal Unit 5955001052067 001052067 CR55/U18M88500 MIL-C-3098/33
CR55/U26M24999 MIL-C-3098/33 An item which consists of a quartz crystal resonator(s), suitably
fsg-59/fsc-5955/us 5955-00-105-2067 Quartz Crystal Unit 5955001052067 001052067 CR55/U18M88500 MIL-C-3098/33
290-4481-000 CR55/U35M72040 MIL-C-3098/33 An item which consists of a quartz crystal resonator
Quartz Crystal Unit 5955001052058 001052058 CR55/U17M98500 MIL-C-3098/33 An item which consists
An item which consists of a quartz crystal resonator(s), suitably CR55/U26M24999 MIL-C-3098/33 An
Quartz Crystal Unit 5955001052058 001052058 CR55/U17M98500 MIL-C-3098/33 An item which consists
An item which consists of a quartz crystal resonator(s), suitably CR55/U26M24999 MIL-C-3098/33 An
Restrictions 5955-00-105-2058
5955-00-105-2058 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5955-00-105-2058
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-00-105-2058
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
Approved Sources 5955-00-105-2058
- Part Number
- Manufacturer
- Status
- CR55/U17M98500
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-3098/33
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-C-3098/33
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5955-00-105-2058
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Drive Level Rating [CQYL]
- 1.6 Milliwatts Minimum And 2.4 Milliwatts Maximum
- Body Thickness [ADPR]
- 0.150 Inches Maximum
- Body Width [ADAT]
- 0.402 Inches Maximum
- Center To Center Distance Between Terminals [CQBK]
- 0.184 Inches Minimum And 0.200 Inches Maximum
- Circuit Resonance [AEHD]
- Series Resonance
- Equivalent Resistance Value In Ohms [CRMP]
- 40.0 Maximum
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.005 To 0.005
- Holder Cover Material [AEHS]
- Metal
- Operating Temp Range [AFGA]
- -55.0 To 105.0 Deg Celsius
- Mode Of Oscillation [AEHC]
- Third Overtone
- Shunt Capacitance In Picofarads [AEHF]
- 7.0 Maximum
- Overall Length [ABHP]
- 0.530 Inches Maximum
- Overall Thickness [ADUM]
- 0.183 Inches Maximum
- Overall Width [ABMK]
- 0.435 Inches Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-C-3098/33 Government Specification
- Specified Frequency [AEHG]
- 17.985 Megahertz
- Style Designator [STYL]
- Oval Body, Wire Leads
- Terminal Diameter [AEBT]
- 0.016 Inches Minimum And 0.019 Inches Maximum
- Terminal Length [ABJT]
- 0.500 Inches Minimum
- Test Data Document [TEST]
- 81349-Mil-C-3098 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
