5955-00-103-2638
Quartz Crystal Unit
5955001032638 001032638 GA53762L27
An item which consists of a quartz crystal resonator(s), suitably mounted in a HOLDER, QUARTZ CRYSTAL. View more Quartz Crystal Unit
May 2023
9
Marketplace 5955-00-103-2638
Request a Quotation from participating marketplace vendors
Related Documents 5955-00-103-2638 5+ Documents (More...)
United States (US) 4. 5955-00-103-2638 Marketplace Restrictions Approved Sources Datasheet Management
BUY NE FedMall Updated Every Day 5955-00-103-2638 RQST NE Related Documents 5955-00-103-2638 1+
Restrictions 5955-00-103-2638
5955-00-103-2638 is a Quartz Crystal Unit that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5955-00-103-2638
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5955-00-103-2638
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
Approved Sources 5955-00-103-2638
- Part Number
- Manufacturer
- Status
- GA53762L27
- Manufacturer
- 56540 - Associated Aircraft Manufacturing & (Active)
- Primary Buy
- Primary Buy
- GA53762L27
- 01714 - Lucent Technologies Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GA53762L27
- 06KW9 - Lucent Technologies Inc Dba Federal (Replaced)
- Advisory Reference
- Advisory Reference
Datasheet 5955-00-103-2638
- Characteristic
- Specifications
- FIIG
- Specifications
- A059A0
- Drive Level Rating [CQYL]
- 200.0 Microamperes Nominal
- Center To Center Distance Between Terminals [CQBK]
- 0.266 Nominal Inches
- Circuit Resonance [AEHD]
- Antiresonance
- Diameter [ABMZ]
- 0.705 Inches Minimum And 0.715 Inches Maximum
- Distance Between Center Terminal And Outside Terminal Centers [AEHV]
- 0.133 Inches Nominal
- Equivalent Resistance Value In Ohms [CRMP]
- 710.0 Nominal
- Frequency Tolerance For Operating Temp In Percent [CRFX]
- -0.001/+0.002
- Holder Cover Material [AEHS]
- Metal
- Operating Temp Range [AFGA]
- +15.0/+45.0 Deg Celsius
- Overall Diameter [ADAV]
- 0.875 Inches Maximum
- Mode Of Oscillation [AEHC]
- Fundamental
- Load Capacitance In Picofarads [AEHE]
- 35.0 Nominal And 34.7 Minimum And 35.4 Maximum
- Second Center To Center Distance Between Terminals [CRLM]
- 0.266 Inches Nominal
- Shunt Capacitance In Picofarads [AEHF]
- 4.2 Nominal And 3.6 Minimum And 4.8 Maximum
- Overall Length [ABHP]
- 2.060 Inches Minimum And 2.120 Inches Maximum
- Specified Frequency [AEHG]
- 159.000 Kilohertz
- Style Designator [STYL]
- Hat Type, 5 Wire Leads
- Terminal Diameter [AEBT]
- 0.040 Inches Nominal
- Terminal Length [ABJT]
- 0.281 Inches Nominal
DLA Procurement Analysis 5955-00-103-2638
Management Data 5955-00-103-2638
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5955-00-103-2638
Freight Information 5955-00-103-2638
5955-00-103-2638 has freight characteristics managed by the Office od the Secretary of HEW.It has a National Motor Freight Classification (NMFC) of 063025. A Sub NMFC of Z. It has a NMFC Description of SEMICONDUCTORS/DEVICES NOI ETC. 5955-00-103-2638 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34525 which rates the freight between FCL and LCL. 5955-00-103-2638 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5955-00-103-2638 is not classified as a special type of cargo when transported by water. 5955-00-103-2638 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5955-00-103-2638
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5955-00-103-2638 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
