5950-00-816-3334
Radio Frequency Coil
5950008163334 008163334 9017178 10100-528
An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes FILTER (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see TRANSFORMER, RADIO FREQUENCY. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see SUPPRESSOR, PARASITIC. View more Radio Frequency Coil
May 2023
22
Marketplace 5950-00-816-3334
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-816-3334 5+ Documents (More...)
RQST NE Updated Every Day 5950-00-816-3334 RQST Updated Every Day 5950-00-816-3334 RQST NE Related
Documents 5950-00-816-3334 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5950/us 5950
Restrictions 5950-00-816-3334
5950-00-816-3334 is a Radio Frequency Coil that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-816-3334
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-816-3334
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5950-00-816-3334
- Part Number
- Manufacturer
- Status
- 10100-528
- Manufacturer
- 59474 - Jeffers Electronics Inc (Obsolete)
- Original Design
- Original Design
- 9017178
- 18876 - Us Army Aviation And Missile Command (Active)
- Secondary Buy
- Secondary Buy
- 10100-528
- 78429 - Carbon/Graphite Group Inc The (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5950-00-816-3334
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Terminal Type And Quantity [TTQY]
- 2 Wire Lead
- Winding Conductor Size [CQPZ]
- 0.02535 Inches American Wire Gage Single Component Single Winding
- Dc Resistance Rating In Ohms [CRGS]
- 0.150 Single Component Single Winding
- Inductance Rating [ACYV]
- 0.68 Microhenries Nominal Single Component Single Winding
- Coil Form Type [ACZP]
- Solid Single Component
- Mounting Method [AXGY]
- Terminal Single Group
- Inclosure Type [AKNA]
- Fully Inclosed
- Body Length [ADAQ]
- 0.438 Inches Nominal
- Overall Diameter [ADAV]
- 0.188 Inches Nominal
Similar Supply Items to 5950-00-816-3334
Freight Information 5950-00-816-3334
5950-00-816-3334 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063420. A Sub NMFC of Z. It has a NMFC Description of TRANSFORMERS,NOI,OR TRANSFORMER PAR. 5950-00-816-3334 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5950-00-816-3334 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35355 which rates the freight between FCL and LCL. 5950-00-816-3334 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-816-3334 is not classified as a special type of cargo when transported by water. 5950-00-816-3334 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
