5950-00-686-6834
Radio Frequency Coil
5950006866834 006866834 6982 712099-71 11308
An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes FILTER (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see TRANSFORMER, RADIO FREQUENCY. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see SUPPRESSOR, PARASITIC. View more Radio Frequency Coil
May 2023
18
Marketplace 5950-00-686-6834
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-686-6834 5+ Documents (More...)
United States (US) 4. 5950-00-686-6834 Marketplace Restrictions Approved Sources Datasheet Management
Quotation Subscribe to View Vendor Details... 6982 COIL,RADIO FREQUENCY 6 EA NS Request Quotation 6982
Restrictions 5950-00-686-6834
5950-00-686-6834 is a Radio Frequency Coil that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-686-6834
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-686-6834
- US Army (A918)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- CL
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Apr 1991
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Sep 2009
Approved Sources 5950-00-686-6834
- Part Number
- Manufacturer
- Status
- 11308
- Manufacturer
- 04203 - A C Electronics Inc (Obsolete)
- Original Design
- Original Design
- 6982
- 03550 - Vanguard Electronics Co (Active)
- Secondary Buy
- Secondary Buy
- 712099-71
- 05869 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5950-00-686-6834
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Body Length [ADAQ]
- 0.690 Inches Nominal
- Coil Form Type [ACZP]
- Solid Single Component
- Dc Resistance Rating In Ohms [CRGS]
- 17.500 Single Component Single Winding
- Mounting Method [AXGY]
- Terminal Single Group
- Inclosure Type [AKNA]
- Fully Inclosed
- Inductance Rating [ACYV]
- 2.50 Millihenries Nominal Single Component Single Winding
- Rating Method [BKPL]
- Winding Turns Single Component Single Winding And Electrical Single Component Single Winding
- Reliability Indicator [AARG]
- Not Established
- Overall Diameter [ADAV]
- 0.380 Inches Nominal
- Turn Quantity [ABHY]
- 450 Single Component Single Winding
- Winding Conductor Size [CQPZ]
- 0.00397 Inches American Wire Gage Single Component Single Winding
- Winding Operating Current [CRBZ]
- 150.0 Milliamperes Dc Maximum Single Component Single Winding
- Terminal Type And Quantity [TTQY]
- 2 Wire Lead
DLA Procurement Analysis 5950-00-686-6834
Management Data 5950-00-686-6834
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5950-00-686-6834
Freight Information 5950-00-686-6834
5950-00-686-6834 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061980. A Sub NMFC of X. It has a NMFC Description of FIELD COILS GENERATOR/MOTOR. 5950-00-686-6834 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34700 which rates the freight between FCL and LCL. 5950-00-686-6834 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-686-6834 is not classified as a special type of cargo when transported by water. 5950-00-686-6834 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5950-00-686-6834
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5950-00-686-6834 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
