5950-00-686-6831
Radio Frequency Coil
5950006866831 006866831 CRF137 712099-038 11331 10-1137
An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes FILTER (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see TRANSFORMER, RADIO FREQUENCY. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see SUPPRESSOR, PARASITIC. View more Radio Frequency Coil
May 2023
20
Marketplace 5950-00-686-6831
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-686-6831 5+ Documents (More...)
Details... 11331 COIL,RADIO FREQUENCY 15 EA NS Request Quotation Updated Every Day 5950-00-686-6831
RQST NE Updated Every Day 5950-00-686-6831 RQST Updated Every Day 5950-00-686-6831 RQST NE Related Documents
,LINEAR 25 EA NS Request Quotation Subscribe to View Vendor Details... 11331 RESOLVER,ELECTRICAL,LINEAR
65 EA NS Request Quotation Subscribe to View Vendor Details... 11331 RESOLVER,ELECTRICAL,LINEAR RQST
YN119717-11331 A deformable material which prevents the passage of matter through the joint formed when
119717-11331YN119717-11331 A deformable material which prevents the passage of matter through the joint
Restrictions 5950-00-686-6831
5950-00-686-6831 is a Radio Frequency Coil that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-686-6831
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-686-6831
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5950-00-686-6831
- Part Number
- Manufacturer
- Status
- CRF137
- Manufacturer
- 99684 - Ratigan Electronics Inc (Obsolete)
- Primary Buy
- Primary Buy
- 712099-038
- 82577 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- 11331
- 04203 - A C Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 10-1137
- 99684 - Ratigan Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5950-00-686-6831
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Terminal Type And Quantity [TTQY]
- 2 Wire Lead
- Winding Operating Current [CRBZ]
- 50.0 Milliamperes Dc Maximum Single Component Single Winding
- Dc Resistance Rating In Ohms [CRGS]
- 400.000 Single Component Single Winding
- Inductance Rating [ACYV]
- 10.00 Millihenries Nominal Single Component Single Winding
- Coil Form Type [ACZP]
- Solid Single Component
- Mounting Method [AXGY]
- Terminal Single Group
- Inclosure Type [AKNA]
- Fully Inclosed
- Body Length [ADAQ]
- 1.500 Inches Nominal
- Body Outside Diameter [ADAR]
- 0.625 Inches Nominal
Similar Supply Items to 5950-00-686-6831
Freight Information 5950-00-686-6831
5950-00-686-6831 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063420. A Sub NMFC of Z. It has a NMFC Description of TRANSFORMERS,NOI,OR TRANSFORMER PAR. 5950-00-686-6831 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5950-00-686-6831 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35355 which rates the freight between FCL and LCL. 5950-00-686-6831 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-686-6831 is not classified as a special type of cargo when transported by water. 5950-00-686-6831 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
