5950-00-686-6830
Radio Frequency Coil
5950006866830 006866830 712099-040 6978 CRF132R 11315
An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes FILTER (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see TRANSFORMER, RADIO FREQUENCY. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see SUPPRESSOR, PARASITIC. View more Radio Frequency Coil
May 2023
24
Marketplace 5950-00-686-6830
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-686-6830 5+ Documents (More...)
Details... 6978 COIL,RADIO FREQUENCY 1 EA NS Request Quotation Updated Every Day 5950-00-686-6830 RQST
NE Updated Every Day 5950-00-686-6830 RQST Updated Every Day 5950-00-686-6830 RQST NE Related Documents
-904-1116 Refrigerant Filter-Drier 4130219041116,11315 9345Posizionatore4920151009345 151009345 A9-11315
to enable JavaScript in your web browser . 4920-15-100-3693Tool Position4920151003693 151003693 A9-11315
Updated Every Day 5962-01-128-0532 RQST Updated https//www.nsnlookup.com /fsg-59/fsc-5950/us 5950-00-686-6830
Radio Frequency Coil 5950006866830 006866830 Day 5950-00-686-6830 RQST NE Related Documents https
Restrictions 5950-00-686-6830
5950-00-686-6830 is a Radio Frequency Coil that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-686-6830
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-686-6830
- US Army (A918)
- Effective Date:
- 1 Nov 2005
- Former MOE Rule:
- A196
- Supplementary Receivers:
- CL
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- France (ZF01)
- Effective Date:
- 1 Jun 2015
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5950-00-686-6830
- Part Number
- Manufacturer
- Status
- CRF132R
- Manufacturer
- 99684 - Ratigan Electronics Inc (Obsolete)
- Original Design
- Original Design
- 712099-040
- 82577 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- 6978
- 03550 - Vanguard Electronics Co (Active)
- Secondary Buy
- Secondary Buy
- 11315
- 04203 - A C Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5950-00-686-6830
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Body Height [ADAU]
- 0.630 Inches Maximum
- Body Length [ADAQ]
- 2.380 Inches Maximum
- Body Width [ADAT]
- 0.630 Inches Maximum
- Coil Form Type [ACZP]
- Solid Single Component
- Dc Resistance Rating In Ohms [CRGS]
- 450.000 Single Component Single Winding
- Distance Between Mounting Facility Centers [AEJN]
- 1.000 Inches Nominal Single Mounting Facility Single Center Group
- Maximum Operating Temp [AEHZ]
- 125.0 Deg Celsius
- Mounting Facility Quantity [AKPV]
- 2 Single Group
- Mounting Hole Diameter [ABTB]
- 0.130 Inches Nominal Single Group
- Mounting Method [AXGY]
- Unthreaded Hole Single Group
- Inclosure Type [AKNA]
- Fully Inclosed
- Inductance Rating [ACYV]
- 20.00 Millihenries Nominal Single Component Single Winding
- Quality Factor [CRHJ]
- 30 Minimum Single Component Single Winding
- Rating Method [BKPL]
- Winding Turns Single Component Single Winding And Electrical Single Component Single Winding
- Reliability Indicator [AARG]
- Not Established
- Overall Height [ABKW]
- 0.630 Inches Maximum
- Overall Length [ABHP]
- 2.380 Inches Maximum
- Overall Width [ABMK]
- 0.630 Inches Maximum
- Turn Quantity [ABHY]
- 4650 Single Component Single Winding
- Winding Conductor Size [CQPZ]
- 0.00315 Inches American Wire Gage Single Component Single Winding
- Winding Operating Current [CRBZ]
- 30.0 Milliamperes Dc Maximum Single Component Single Winding
- Terminal Type And Quantity [TTQY]
- 2 Tab, Solder Lug
DLA Procurement Analysis 5950-00-686-6830
Management Data 5950-00-686-6830
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5950-00-686-6830
Freight Information 5950-00-686-6830
5950-00-686-6830 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061980. A Sub NMFC of X. It has a NMFC Description of FIELD COILS GENERATOR/MOTOR. 5950-00-686-6830 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34700 which rates the freight between FCL and LCL. 5950-00-686-6830 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-686-6830 is not classified as a special type of cargo when transported by water. 5950-00-686-6830 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5950-00-686-6830
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5950-00-686-6830 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
