5950-00-686-6827
Radio Frequency Coil
5950006866827 006866827 CRF100 6980 11316
An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes FILTER (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see TRANSFORMER, RADIO FREQUENCY. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see SUPPRESSOR, PARASITIC. View more Radio Frequency Coil
May 2023
19
Marketplace 5950-00-686-6827
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-686-6827 5+ Documents (More...)
Photo 1/2 5950-00-686-6827 Photo 2/2 - - 1.
RQST NE Updated Every Day 5950-00-686-6827 RQST Updated Every Day 5950-00-686-6827 RQST NE Related
Radio Frequency Coil 5950006866827 006866827 www.nsnlookup.com /fsg-59/fsc-5950/us 5950-00-686-
$1 a day Upgrade your Account Upgrade 5998-01-292 -3572Circuit Card Assembly5998012923572 012923572 11316
https//www.nsnlookup.com /fsg-66/fsc-6605/au 6605-66-077-8703 Signal Box 6605660778703 660778703,12-11316
99-911-4687 Nipple 4730999114687 999114687,11316,4A/4945 5798Cartridge Fuse5920144785798 144785798 11316
JavaScript in your web browser . 8455-33-211-1402Branch Of Service Insignia8455332111402 332111402 ET-11316
Radio Frequency Coil 5950006866827 006866827 5798Cartridge Fuse5920144785798 144785798 11316 https
8455/es 8455-33-209-4504 Branch Of Service Insignia 8455332094504 Insignia8455332111402 332111402 ET-11316
Radio Frequency Coil 5950006866827 006866827 JavaScript in your web browser . 8455-33-211-1402Branch
Restrictions 5950-00-686-6827
5950-00-686-6827 is a Radio Frequency Coil that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-686-6827
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-686-6827
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5950-00-686-6827
- Part Number
- Manufacturer
- Status
- CRF100
- Manufacturer
- 99684 - Ratigan Electronics Inc (Obsolete)
- Primary Buy
- Primary Buy
- 6980
- 03550 - Vanguard Electronics Co (Active)
- Secondary Buy
- Secondary Buy
- 11316
- 04203 - A C Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5950-00-686-6827
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Terminal Type And Quantity [TTQY]
- 2 Wire Lead
- Turn Quantity [ABHY]
- 126 Single Component Single Winding
- Winding Conductor Size [CQPZ]
- 0.00353 Inches American Wire Gage Single Component Single Winding
- Winding Operating Current [CRBZ]
- 25.0 Milliamperes Dc Maximum Single Component Single Winding
- Dc Resistance Rating In Ohms [CRGS]
- 15.000 Single Component Single Winding
- Inductance Rating [ACYV]
- 100.00 Microhenries Nominal Single Component Single Winding
- Coil Form Type [ACZP]
- Solid Single Component
- Mounting Method [AXGY]
- Terminal Single Group
- Inclosure Type [AKNA]
- Fully Inclosed
- Body Length [ADAQ]
- 0.500 Inches Nominal
- Overall Diameter [ADAV]
- 0.380 Inches Nominal
- Reliability Indicator [AARG]
- Not Established
NATO Stock Numbers Related to 5950-00-686-6827
Freight Information 5950-00-686-6827
5950-00-686-6827 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063420. A Sub NMFC of Z. It has a NMFC Description of TRANSFORMERS,NOI,OR TRANSFORMER PAR. 5950-00-686-6827 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5950-00-686-6827 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35355 which rates the freight between FCL and LCL. 5950-00-686-6827 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-686-6827 is not classified as a special type of cargo when transported by water. 5950-00-686-6827 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
