5950-00-647-7036
Audio Frequency Transformer
5950006477036 006477036 S2259-2
A transformer which is designed so that part or all of its range of operating frequencies is 20 kilohertz (kilocycles) and below. The maximum value may extend into the radio frequency range. It is generally used in the input, output, amplifier, or oscillator stages of audio and sonar devices. View more Audio Frequency Transformer
May 2023
4
Marketplace 5950-00-647-7036
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-647-7036 5+ Documents (More...)
... ) https//www.nsnlookup.com /fsg-59/fsc-5950/us 5950-00-647-7036 Audio Frequency Transformer 5950006477036
00 ... ) https//www.nsnlookup.com /fsg-59/fsc-5950/us 5950-00-647-7036 Audio Frequency Transformer 5950006477036
Audio Frequency Transformer 5950006477036 day Upgrade your Account Upgrade 5950-00-647-7036Audio
Frequency Transformer5950006477036 006477036 S2259 S2259-2 TRANSFORMER,AUDIO FREQUENCY RQST NS Request
Audio Frequency Transformer 5950006477036 day Upgrade your Account Upgrade 5950-00-647-7036Audio
Frequency Transformer5950006477036 006477036 S2259 S2259-2 TRANSFORMER,AUDIO FREQUENCY RQST NS Request
Anonyme De (Replaced) Secondary Buy RNCC 5 RNVC 2 DAC 1 Similar Supply Items to 5950-14-275-0987 5950-00-647-7036
Restrictions 5950-00-647-7036
5950-00-647-7036 is a Audio Frequency Transformer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-647-7036
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-647-7036
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5950-00-647-7036
- Part Number
- Manufacturer
- Status
- S2259-2
- Manufacturer
- 72149 - Electronic Transformer Corp (Active)
- Primary Buy
- Primary Buy
Datasheet 5950-00-647-7036
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Body Height [ADAU]
- 7.875 Inches Nominal
- Body Length [ADAQ]
- 7.000 Inches Nominal
- Body Width [ADAT]
- 5.250 Inches Nominal
- Center To Center Distance Between Mounting Facilities Parallel To Length [ABKQ]
- 6.125 Inches Nominal Single Mounting Facility Single Center Group
- Center To Center Distance Between Mounting Facilities Parallel To Width [ABKR]
- 6.125 Inches Nominal Single Mounting Facility Single Center Group
- Frequency Rating [ACZB]
- 100.0 Hertz Minimum Single Component And 4.5 Kilohertz Maximum Single Component
- Maximum Transformer Power Rating [ACZF]
- 355.0 Watts Single Component
- Mounting Facility Quantity [AKPV]
- 4 Single Group
- Mounting Method [AXGY]
- Threaded Hole Single Group
- Nominal Thread Size [CQJX]
- 0.250 Inches Single Group
- Impedance Rating In Ohms [ACYW]
- 22000.0 Nominal Single Component Single Primary
- Impedance Rating In Ohms [ACYW]
- 6000.0 Nominal Single Component Single Secondary And 7000.0 Nominal Single Component Single Secondary And 8000.0 Nominal Single Component Single Secondary
- Inclosure Type [AKNA]
- Hermetically Sealed
- Primary To Secondary Turn Ratio [ACZH]
- 1 To 1-5/8 Single Component
- Reliability Indicator [AARG]
- Not Established
- Winding Function And Quantity [BPLC]
- 1 Primary Single Component And 1 Secondary Single Component
- Winding Operating Current [CRBZ]
- 130.0 Milliamperes Dc Maximum Single Component Single Primary
- Winding Operating Current [CRBZ]
- 340.0 Milliamperes Dc Maximum Single Component Single Secondary
- Terminal Type And Quantity [TTQY]
- 7 Standoff, Solder Lug
- Thread Quantity Per Inch [CMLP]
- 20 Single Group
- Thread Series Designator [THSD]
- Unc Single Group
DLA Procurement Analysis 5950-00-647-7036
Management Data 5950-00-647-7036
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5950-00-647-7036
Freight Information 5950-00-647-7036
5950-00-647-7036 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063420. A Sub NMFC of Z. It has a NMFC Description of TRANSFORMERS,NOI,OR TRANSFORMER PAR. 5950-00-647-7036 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35355 which rates the freight between FCL and LCL. 5950-00-647-7036 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-647-7036 is not classified as a special type of cargo when transported by water. 5950-00-647-7036 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5950-00-647-7036
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
