5950-00-590-2157
Radio Frequency Transformer
5950005902157 005902157 712099-61 6797 11205
An item having either a single tapped winding (autotransformer type), or two or more windings designed to furnish inductive reactance and/or transfer electrical energy in circuits by means of a magnetic field. It is so designed that its entire intended range of operations is above 20 Kilohertz (Kilocycles). The minimum value may extend into the audio frequency range (below 20 Kilohertz). It may include integral capacitors, coils, resistors, and adjustable tuning cores. For items having only two active terminals see COIL, RADIO FREQUENCY. Includes types having windings which may be moved with respect to each other. Excludes TRANSFORMER, DISCRIMINATOR. View more Radio Frequency Transformer
May 2023
10
Marketplace 5950-00-590-2157
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-590-2157 5+ Documents (More...)
United States (US) 4. 5950-00-590-2157 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 5950-00-590-2157 RQST Updated Every Day 5950-00-590-2157 RQST NE Related
5998993243166993243166 JavaScript in your web browser . 5998-99-324-3166Printed Circuit Board5998993243166 993243166334-11205
00104274211205 https https 590 https//www.nsnlookup.com https//www.nsnlookup.com /fsg-59/fsc-5950/us 5950-00-590-2157
/fsg-59/fsc-5995/au
enable JavaScript in your web browser . 5995-66-142-6234Wiring Harness5995661426234 66142623444-79-11205
enable JavaScript in your web browser . 5995-66-142-6234Wiring Harness5995661426234 661426234 44-79-11205
Restrictions 5950-00-590-2157
5950-00-590-2157 is a Radio Frequency Transformer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-590-2157
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-590-2157
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5950-00-590-2157
- Part Number
- Manufacturer
- Status
- 712099-61
- Manufacturer
- 82577 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- 6797
- 03550 - Vanguard Electronics Co (Active)
- Secondary Buy
- Secondary Buy
- 11205
- 04203 - A C Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 712099-61
- 05869 - Raytheon Company (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5950-00-590-2157
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Terminal Type And Quantity [TTQY]
- 3 Tab, Solder Lug
- Rating Method [BKPL]
- Winding Turns Single Component Single Primary
- Turn Quantity [ABHY]
- 1500 Single Component Single Primary
- Winding Conductor Size [CQPZ]
- 0.00397 Inches American Wire Gage Single Component Single Primary
- Frequency Rating [ACZB]
- 80.0 Kilohertz Maximum Single Component
- Coil Form Type [ACZP]
- Hollow Single Component
- Adjustment Method And Quantity [CTHD]
- 1 Adjustable Core Single Component
- Adjustment Device Drive Type [ACZU]
- Slotted Screw Single Component
- Winding Function And Quantity [BPLC]
- 1 Primary Single Component
- Mounting Method [AXGY]
- Threaded Stud Single Group
- Mounting Facility Quantity [AKPV]
- 2 Single Group
- Thread Series Designator [THSD]
- Unc Single Group
- Nominal Thread Size [CQJX]
- 0.138 Inches Single Group
- Thread Quantity Per Inch [CMLP]
- 32 Single Group
- Distance Between Mounting Facility Centers [AEJN]
- 0.812 Inches Nominal Single Mounting Facility Single Center Group
- Inclosure Type [AKNA]
- Partially Inclosed, Half Shell
- Body Length [ADAQ]
- 1.750 Inches Nominal
- Body Outside Diameter [ADAR]
- 1.250 Inches Nominal
- Reliability Indicator [AARG]
- Not Established
DLA Procurement Analysis 5950-00-590-2157
Management Data 5950-00-590-2157
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5950-00-590-2157
Freight Information 5950-00-590-2157
5950-00-590-2157 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063420. A Sub NMFC of Z. It has a NMFC Description of TRANSFORMERS,NOI,OR TRANSFORMER PAR. 5950-00-590-2157 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35355 which rates the freight between FCL and LCL. 5950-00-590-2157 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-590-2157 is not classified as a special type of cargo when transported by water. 5950-00-590-2157 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5950-00-590-2157
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-1249, Paper, Tissue
- No Requirement
- Not Applicable
- --
- No special marking
- A-A-1249, Paper, Tissue
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
