5950-00-586-7237
Radio Frequency Transformer
5950005867237 005867237 6796 11206
An item having either a single tapped winding (autotransformer type), or two or more windings designed to furnish inductive reactance and/or transfer electrical energy in circuits by means of a magnetic field. It is so designed that its entire intended range of operations is above 20 Kilohertz (Kilocycles). The minimum value may extend into the audio frequency range (below 20 Kilohertz). It may include integral capacitors, coils, resistors, and adjustable tuning cores. For items having only two active terminals see COIL, RADIO FREQUENCY. Includes types having windings which may be moved with respect to each other. Excludes TRANSFORMER, DISCRIMINATOR. View more Radio Frequency Transformer
May 2023
8
Marketplace 5950-00-586-7237
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-586-7237 5+ Documents (More...)
Every Day 5950-00-586-7237 RQST Updated Every Day 5950-00-586-7237 RQST NE Related Documents 5950-00
type), or two or more windings Every Day 5950-00-586-7237 RQST Updated Every Day 5950-00-586-7237 RQST
Restrictions 5950-00-586-7237
5950-00-586-7237 is a Radio Frequency Transformer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-586-7237
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-586-7237
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5950-00-586-7237
- Part Number
- Manufacturer
- Status
- 11206
- Manufacturer
- 04203 - A C Electronics Inc (Obsolete)
- Original Design
- Original Design
- 6796
- 03550 - Vanguard Electronics Co (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5950-00-586-7237
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Adjustment Device Drive Type [ACZU]
- Slotted Screw Single Component
- Adjustment Method And Quantity [CTHD]
- 1 Adjustable Core Single Component
- Body Length [ADAQ]
- 1.750 Inches Nominal
- Body Outside Diameter [ADAR]
- 1.250 Inches Nominal
- Coil Form Type [ACZP]
- Hollow Single Component
- Distance Between Mounting Facility Centers [AEJN]
- 0.812 Inches Nominal Single Mounting Facility Single Center Group
- Frequency Rating [ACZB]
- 20.0 Kilohertz Maximum Single Component
- Mounting Facility Quantity [AKPV]
- 2 Single Group
- Mounting Method [AXGY]
- Threaded Stud Single Group
- Nominal Thread Size [CQJX]
- 0.138 Inches Single Group
- Inclosure Type [AKNA]
- Fully Inclosed
- Inductance Rating [ACYV]
- 228.00 Millihenries Nominal Single Component Single Primary
- Rating Method [BKPL]
- Winding Turns Single Component Single Primary And Electrical Single Component Single Primary
- Reliability Indicator [AARG]
- Not Established
- Special Features [FEAT]
- Tapped At 404 Turns
- Turn Quantity [ABHY]
- 3200 Single Component Single Primary
- Winding Conductor Size [CQPZ]
- 0.00397 Inches American Wire Gage Single Component Single Primary
- Winding Function And Quantity [BPLC]
- 1 Primary Single Component
- Terminal Type And Quantity [TTQY]
- 3 Tab, Solder Lug
- Thread Quantity Per Inch [CMLP]
- 32 Single Group
- Thread Series Designator [THSD]
- Unc Single Group
DLA Procurement Analysis 5950-00-586-7237
Management Data 5950-00-586-7237
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5950-00-586-7237
Freight Information 5950-00-586-7237
5950-00-586-7237 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063420. A Sub NMFC of Z. It has a NMFC Description of TRANSFORMERS,NOI,OR TRANSFORMER PAR. 5950-00-586-7237 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35355 which rates the freight between FCL and LCL. 5950-00-586-7237 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-586-7237 is not classified as a special type of cargo when transported by water. 5950-00-586-7237 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5950-00-586-7237
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-1249, Paper, Tissue
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- --
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- A-A-1249, Paper, Tissue
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
Contracting Technical Data File (CTDF) 5950-00-586-7237 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
