5950-00-586-7066
Radio Frequency Coil
5950005867066 005867066 919455-517 712099-053REVA 6750 11432 CRF203
An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes FILTER (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see TRANSFORMER, RADIO FREQUENCY. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see SUPPRESSOR, PARASITIC. View more Radio Frequency Coil
May 2023
11
Marketplace 5950-00-586-7066
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-586-7066 5+ Documents (More...)
Photo 1/5 5950-00-586-7066 Photo 2/5 5950-00-586-7066 Photo 3/5 5950-00-586-7066 Photo 4/5 5950
Quotation Subscribe to View Vendor Details... 11432 COIL,RADIO FREQUENCY RQST NS Request Quotation 6750
/www.nsnlookup.com /fsg-61/fsc-6130/us 6130-01-630-4464 Power Supply 6130016304464 016304464,11432 11432
JavaScript in your web browser . 6605-99-521-3801Compass Alarm Panel6605995213801 995213801CD11432CD 11432
-A1 (241)A7904A.11432-A1 A rigid, portable shelter designed for the protection of personnel/equipment
. 5411-15-177- 4643Expandable Shelter5411151774643 151774643A.11432 -A1 (241)A7904A.11432-A1 A rigid
(241)AC023480-11432 An indicator unit on which computer information is visually displayed.
(241)AC023480-11432 An indicator unit on which computer information is visually displayed.
https//www.nsnlookup.com /fsg-53/fsc-5330/ca 5330-20-005-3081 Gasket 5330200053081 200053081,11432 -11432
-A1 (241)A7904A.11432-A1 A rigid, portable shelter designed for the protection of personnel/equipment
Restrictions 5950-00-586-7066
5950-00-586-7066 is a Radio Frequency Coil that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-586-7066
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-586-7066
- US Army (A918)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- CL
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5950-00-586-7066
- Part Number
- Manufacturer
- Status
- 712099-053REVA
- Manufacturer
- 05869 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- 919455-517
- 82577 - Raytheon Company (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 6750
- 03550 - Vanguard Electronics Co (Active)
- Secondary Buy
- Secondary Buy
- 712099-053REVA
- 82577 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- 11432
- 04203 - A C Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- CRF203
- 99684 - Ratigan Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5950-00-586-7066
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Body Length [ADAQ]
- 1.000 Inches Maximum
- Body Outside Diameter [ADAR]
- 0.320 Inches Maximum
- Coil Form Type [ACZP]
- Solid Single Component
- Dc Resistance Rating In Ohms [CRGS]
- 15.000 Single Component Single Winding
- Mounting Method [AXGY]
- Terminal Single Group
- Inclosure Type [AKNA]
- Fully Inclosed
- Inductance Rating [ACYV]
- 2.50 Millihenries Nominal Single Component Single Winding
- Quality Factor [CRHJ]
- 80 Minimum Single Component Single Winding
- Rating Method [BKPL]
- Winding Turns Single Component Single Winding And Electrical Single Component Single Winding
- Reliability Indicator [AARG]
- Not Established
- Turn Quantity [ABHY]
- 137 Single Component Single Winding
- Winding Conductor Size [CQPZ]
- 0.00445 Inches American Wire Gage Single Component Single Winding
- Winding Operating Current [CRBZ]
- 50.0 Milliamperes Dc Maximum Single Component Single Winding
- Terminal Type And Quantity [TTQY]
- 2 Wire Lead
DLA Procurement Analysis 5950-00-586-7066
Management Data 5950-00-586-7066
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 5950-00-586-7066
Freight Information 5950-00-586-7066
5950-00-586-7066 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061980. A Sub NMFC of X. It has a NMFC Description of FIELD COILS GENERATOR/MOTOR. 5950-00-586-7066 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34700 which rates the freight between FCL and LCL. 5950-00-586-7066 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-586-7066 is not classified as a special type of cargo when transported by water. 5950-00-586-7066 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5950-00-586-7066
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
Contracting Technical Data File (CTDF) 5950-00-586-7066 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
