5950-00-060-1199
Audio Frequency Transformer
5950000601199 000601199 8010483 GA50941
A transformer which is designed so that part or all of its range of operating frequencies is 20 kilohertz (kilocycles) and below. The maximum value may extend into the radio frequency range. It is generally used in the input, output, amplifier, or oscillator stages of audio and sonar devices. View more Audio Frequency Transformer
May 2023
19
Marketplace 5950-00-060-1199
Request a Quotation from participating marketplace vendors
Related Documents 5950-00-060-1199 3+ Documents (More...)
United States (US) 4. 5950-00-060-1199 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 5950-00-060-1199 RQST Updated Every Day 5950-00-060-1199 RQST NE Related Documents
Restrictions 5950-00-060-1199
5950-00-060-1199 is a Audio Frequency Transformer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5950-00-060-1199
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5950-00-060-1199
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 5950-00-060-1199
- Part Number
- Manufacturer
- Status
- 8010483
- Manufacturer
- 18876 - Us Army Aviation And Missile Command (Active)
- Primary Buy
- Primary Buy
- GA50941
- 64959 - American Telephone And Telegraph Co (Replaced)
- Original Design
- Original Design
- GA50941
- 06KW9 - Lucent Technologies Inc Dba Federal (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- GA50941
- 3B4M0 - Lucent Technologies Inc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5950-00-060-1199
- Characteristic
- Specifications
- FIIG
- Specifications
- A058B0
- Body Height [ADAU]
- 2.062 Inches Nominal
- Body Length [ADAQ]
- 1.656 Inches Nominal
- Body Width [ADAT]
- 1.218 Inches Nominal
- Distance Between Mounting Facility Centers [AEJN]
- 0.750 Inches Nominal Single Mounting Facility Single Center Group
- Frequency Rating [ACZB]
- 200.0 Hertz Minimum Single Component And 6.0 Kilohertz Maximum Single Component
- Maximum Transformer Power Rating [ACZF]
- 37.0 Decibels Single Component
- Mounting Facility Quantity [AKPV]
- 2 Single Group
- Mounting Method [AXGY]
- Threaded Hole Single Group
- Nominal Thread Size [CQJX]
- 0.138 Inches Single Group
- Impedance Rating In Ohms [ACYW]
- 120.0 Nominal Single Component Single Secondary
- Impedance Rating In Ohms [ACYW]
- 60.0 Nominal Single Component Single Primary
- Inclosure Type [AKNA]
- Hermetically Sealed
- Reliability Indicator [AARG]
- Not Established
- Winding Function And Quantity [BPLC]
- 1 Primary Single Component And 1 Secondary Single Component
- Terminal Type And Quantity [TTQY]
- 5 Standoff, Solder Lug
- Thread Quantity Per Inch [CMLP]
- 32 Single Group
- Thread Series Designator [THSD]
- Unc Single Group
- Transformer Function [ACYE]
- Line
Similar Supply Items to 5950-00-060-1199
Freight Information 5950-00-060-1199
5950-00-060-1199 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 063420. A Sub NMFC of Z. It has a NMFC Description of TRANSFORMERS,NOI,OR TRANSFORMER PAR. 5950-00-060-1199 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 5950-00-060-1199 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35355 which rates the freight between FCL and LCL. 5950-00-060-1199 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 595 for ocean manifesting and military sealift. 5950-00-060-1199 is not classified as a special type of cargo when transported by water. 5950-00-060-1199 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5950-00-060-1199
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Special Requirements
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Special requirement – See specific instructions or drawings provided
